Latex Printer 4,000 W | TrueVIS AP-640 for sale from Prytec Solutions

Latex Printer 4,000 W | TrueVIS AP-640

Supplier: Prytec Solutions

Latex Printer 4,000 W | TrueVIS AP-640

The premium 4-colour large format latex printer that delivers superior quality, consistency, and reliability over the rest.

Video for Latex Printer 4,000 W | TrueVIS AP-640

Receive 1-3 days from order

Switch to a latex printer that leaves the competition behind. Designed for professionals who demand exceptional print quality, dependable performance, and maximum efficiency, the TrueVIS AP-640 sets a new standard in the industry.

Unmatched performance and vibrant results across a wide range of media.
Superior consistency and reliability with stable and accurate printing over longer periods of time.
Lower operating costs and easier maintenance with Roland DG’s advanced inks, features, and technology.

Specifications:

		AP-640
Printing method		Piezo ink-jet method
Media	Width	10.2 to 64 in. (259 to 1,625 mm)
	Thickness	Max. 0.039 in. (1.0 mm) with liner
	Roll outer diameter	Max. 9.8 in. (250 mm)
	Roll weight	Max. 99 lb. (45 kg)
	Core diameter	3 in. (76.2 mm) or 2 in. (50.8 mm)
Printing width (*1)		Max. 63.5 in. (1,615 mm)
Ink	Type	Resin ink 700 ml pouch
Ink	Colours	Four colours (cyan, magenta, yellow, and black) and optimizer
Printing resolution (dots per inch)		Max. 1200 dpi
Ink drying system (*2)		Print heater set temperature: 77 to 113°F (25 to 45°C) Dryer set temperature: 158 to 230°F (70 to 110°C)
Connectivity		Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function		Automatic sleep feature
Rated Input		Printer: 200-240 Va.c. 50/60 Hz 3 A Dryer 1: 200-240 Va.c. 50/60 Hz 10 A Dryer 2: 200-240 Va.c. 50/60 Hz 10 A
Power consumption	During operation	Approx. 4,000 W
Power consumption	Sleep mode	Approx. 65 W
Acoustic noise level	During operation	69 dB (A) or less
Acoustic noise level	During standby	53 dB (A) or less
Dimensions (Width x Depth x Height)		113.7 in. × 33 in. × 61.1 in. (2,886 mm × 836 mm × 1,550 mm)
Weight (with stand)		587 lb. (266 kg)
Environment (*3)	During operation	Temperature: 68 to 86 °F (20 to 30 °C), Humidity: 20 to 80 %RH (no condensation)
	Recommended Environment	Temperature: 68 to 77 °F (20 to 25 °C), Humidity: 40 to 60 %RH (no condensation)
	Not operating	Temperature: 41 to 104 °F (5 to 40 °C), Humidity: 20 to 80 %RH (no condensation)
Included items		Dedicated stand, power cords, dryers, media take-up unit, media holders, separating knife, replacement blade, cleaning liquid bottle for maintenance, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect), etc.

*1 The length of printing is subject to the limitations of the program.
*2
- Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment.
- Depending on the ambient temperature and media width, the preset temperature may fail to be reached.
*3 Use the machine in an operating environment within these ranges. Also, printing in the recommended environmental conditions (A) is recommended to prevent or reduce any possible differences in print quality depending on media

To contact Prytec Solutions about Latex Printer 4,000 W | TrueVIS AP-640 use Get a quote.

Unmatched performance and vibrant results across a wide range of media.
Superior consistency and reliability with stable and accurate printing over longer periods of time.
Lower operating costs and easier maintenance with Roland DG’s advanced inks, features, and technology.

Specifications:

		AP-640
Printing method		Piezo ink-jet method
Media	Width	10.2 to 64 in. (259 to 1,625 mm)
	Thickness	Max. 0.039 in. (1.0 mm) with liner
	Roll outer diameter	Max. 9.8 in. (250 mm)
	Roll weight	Max. 99 lb. (45 kg)
	Core diameter	3 in. (76.2 mm) or 2 in. (50.8 mm)
Printing width (*1)		Max. 63.5 in. (1,615 mm)
Ink	Type	Resin ink 700 ml pouch
Ink	Colours	Four colours (cyan, magenta, yellow, and black) and optimizer
Printing resolution (dots per inch)		Max. 1200 dpi
Ink drying system (*2)		Print heater set temperature: 77 to 113°F (25 to 45°C) Dryer set temperature: 158 to 230°F (70 to 110°C)
Connectivity		Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function		Automatic sleep feature
Rated Input		Printer: 200-240 Va.c. 50/60 Hz 3 A Dryer 1: 200-240 Va.c. 50/60 Hz 10 A Dryer 2: 200-240 Va.c. 50/60 Hz 10 A
Power consumption	During operation	Approx. 4,000 W
Power consumption	Sleep mode	Approx. 65 W
Acoustic noise level	During operation	69 dB (A) or less
Acoustic noise level	During standby	53 dB (A) or less
Dimensions (Width x Depth x Height)		113.7 in. × 33 in. × 61.1 in. (2,886 mm × 836 mm × 1,550 mm)
Weight (with stand)		587 lb. (266 kg)
Environment (*3)	During operation	Temperature: 68 to 86 °F (20 to 30 °C), Humidity: 20 to 80 %RH (no condensation)
	Recommended Environment	Temperature: 68 to 77 °F (20 to 25 °C), Humidity: 40 to 60 %RH (no condensation)
	Not operating	Temperature: 41 to 104 °F (5 to 40 °C), Humidity: 20 to 80 %RH (no condensation)
Included items		Dedicated stand, power cords, dryers, media take-up unit, media holders, separating knife, replacement blade, cleaning liquid bottle for maintenance, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect), etc.

*1 The length of printing is subject to the limitations of the program.
*2
- Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment.
- Depending on the ambient temperature and media width, the preset temperature may fail to be reached.
*3 Use the machine in an operating environment within these ranges. Also, printing in the recommended environmental conditions (A) is recommended to prevent or reduce any possible differences in print quality depending on media

Read less...

To contact Prytec Solutions about Latex Printer 4,000 W | TrueVIS AP-640 use Get a quote.

datasheet_ap640_das_0825(0.13MB)
