Flatbed Printers Max. 100 kg/m2 | VersaOBJECT LO/CO-i Series Get latest price

The LO/CO-i Series is the perfect solution for customising boards or objects up to 242 mm in height and even irregular 3D objects.

• Premium quality direct-to-object or substrate printing.
• Special effect printing for added-value products.
• High-volume object customisation and personalisation.
• Available in a size and configuration to suit your business.

Specifications:

Model			LO-640-F3		LO-300-F2	CO-640i-F3	CO-300i-F2
Printing Method			Piezo ink-jet method
Attachable objects to be printed on	Width		Max. 1,625 mm		Max. 762 mm	Max. 1,625 mm	Max. 762 mm
	Thickness		Max. 242 mm
	Weight		Max. 100 kq/m2
Maximum Printing Width/Length			Max. 1,520 × 2,450 mm		Max. 656 × 1,450 mm	Max. 1,612 × 2,500 mm	Max. 749 × 1,500 mm
Ink	Types		ECO-UV (EUV5p) 750 ml pouch (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss, Primer)			ECO-UV (EUV5) 500 ml cartridge(Cyan, Magenta, Yellow, Black, Red, Orange, Gloss, Primer) ECO-UV (EUV5) 220 ml cartridge (White)
	Colours		Eight colours (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss) Seven colours (Cyan, Magenta, Yellow, Black, Red, Orange, White) Seven colours (Cyan, Magenta, Yellow, Black, Red, Orange, White) and Primer Seven colours (Cyan, Magenta, Yellow, Black, Red, White, Gloss) and Primer Six colours (Cyan, Magenta, Yellow, Black, White, Gloss) and Primer Six colours (Cyan, Magenta, Yellow, Black, White, Gloss) Four colours (Cyan, Magenta, Yellow, Black)
Ink-curing Unit			Built-in UV-LED lamp
Printing Resolution (dots per inch)			Max. 1,200 dpi			Max. 1,440 dpi
Connectivity			Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving Function			Automatic sleep feature
Power Requirements			230V 16A 2P+E
Power Consumption	During Operation (100% Vacuum)		Approx. 2.90 kW		Approx. 1.80 kW	Approx. 2.90 kW	Approx. 1.80 kW
	Sleep Mode		Approx. 0.08 kW
Acoustic Noise Level	During Operation		90 dB (A) or less		80 dB (A) or less	90 dB (A) or less	80 dB (A) or less
	During Standby		80 dB (A) or less		70 dB (A) or less	80 dB (A) or less	70 dB (A) or less
Dimensions (Width x Depth x Height)			2,901 mm × 3,457 mm × 1,560 mm (114.3 in. x 136.2 in. x 61.5 in.)		2,037 mm x 2,430 mm x 1,560 mm (80.2 in. x 95.7 in. x 61.5 in.)	2,815 mm × 3,399 mm × 1,469 mm (110.9 in. x 133.9 in. x 57.9 in.)	1,928 mm × 2,384 mm × 1,469 mm (76.0 in. x 93.9 in x 57.9 in.)
Weight			920 kg (2,029 lb.)		526 kg (1,160 lb.)	863 kg (1,903 lb.)	487 kg (1,074 lb.)
Environment	During Operation (*1)		Temperature: 20 to 32 °C (68 to 89.6 °F), Humidity: 35 to 80 %RH (no condensation)
	Not Operating		Temperature: 5 to 40 °C (41 to 104 °F), Humidity: 20 to 80 %RH (no condensation)
Included Items			Power cord, cleaning liquid, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect), etc.

1Operating environment. (Use the machine in an operating environment within these ranges.)
