Direct-to-Film Printer 840W | TY-300 Get latest price

Unleash unparalleled DTF performance and productivity with the TY-300. This powerhouse direct-to-film printer delivers stunning graphics and bold designs for heat transfer onto a wide range of materials, including cotton, polyester, denim, nylon, rayon, and more. Transform custom apparel and textiles with technology that enables you to produce vibrant colours, razor-sharp text, and fine details with unprecedented cost effectiveness, speed, and efficiency.

Welcome to a new generation of DTF printing.

• The TY-300 offers higher print quality than the competition – reproduces colours, detailed images, and even smaller text with amazing accuracy.
• Prints at speeds up to four times faster than competitive models, allowing for optimum productivity.
• Low running costs and reduced ink consumption during printing/cleaning make the TY-300 more cost-efficient than other DTF printers.
• Creates durable apparel and textiles with a “soft hand” feel, natural finish, and outstanding washability.

Specifications:

		TY-300
Printing Method		Piezo ink-jet method
Media	Width	7.2 to 30 in (182 to 762 mm)
	Thickness	Maximum 39.3 mil (1.0 mm) with liner for printing, Maximum 15.7 mil (0.4 mm) with liner and 8.6 mil (0.22 mm) without liner for cutting
	Roll outer diameter	Maximum 9.84 in (250 mm)
	Roll weight	66.1 lb (30 kg)
	Core diameter	3 in (76.2 mm) or 2 in (50.8 mm)
Printing/cutting width (*1)		Maximum 28.9 in (736 mm)
Ink	Type	S-PG2 INK 500 ml cartridge
	Colours	Five colours (cyan, magenta, yellow, black, and white) (2 cartridges)
Printing resolution		Maximum 1,200 dpi
Cutting speed		0.39 to 11.8 in/s (10 to 300 mm/s)
Blade force (*2)		30 to 500 gf
Blade type		CAMM-1 series blade
Blade offset		0.0 to 59 mil (0.000 to 1.500 mm)
Software resolution (cutting)		0.98 mil/step (0.025 mm/step)
Media heating system (*3)		Print heater set temperature: 86 to 104°F (30 to 40°C), Dryer set temperature: 86 to 122°F (30 to 50°C)
Connectivity		Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function		Automatic sleep feature
Rated input		100-120 / 220-240 Vac 50/60 Hz 6.4/3.0 A
Power consumption	During operation	Approx. 840W
	Sleep mode	Approx. 70W
Acoustic noise level	During operation	63 dB (A) or less
	During standby	58 dB (A) or less
Dimensions (Width x Depth x Height)		80 in x 29.5 in x 55.8 in (2,032 mm x 748 mm x 1,415 mm)
Weight		298 lb (135 kg)
Environment	During operation (*4)	68 to 82.4°F (20 to 28°C), Humidity: 40 to 60% RH (no condensation)
	Not operating	41 to 104°F (5 to 40°C), Humidity: 20 to 80% RH (no condensation)
Included Items		Dedicated stand, Power cord, Media holders, Separating knife, Replacement blade, Cleaning liquid, Drain bottle, User's Manual, Software(VersaWorks, Roland DG Connect), etc.

*1	The length of printing or cutting is subject to the limitations of the program.
*2	500 gf is the maximum instantaneous blade force. The blade force must be adjusted according to details such as the media thickness.
*3	Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment. Depending on the ambient temperature and media width, the preset temperature may fail to be reached.
*4	Operating environment (Use in an operating environment within this range.)

Read more...

To contact Prytec Solutions about Direct-to-Film Printer 840W | TY-300 use Get a quote.
