Flatbed Printers 102 mm | VersaSTUDIO BD Series

Supplier: Prytec Solutions

Extraordinary product customisation starts here. The new VersaSTUDIO BD Series makes it quick and easy for anyone — even those with no prior experience — to print vibrant and detailed graphics on a wide range of objects.

Video for Flatbed Printers 102 mm | VersaSTUDIO BD Series

Receive 1-3 days from order

Even better, the BD Series fits on your desktop, making it ideal for use in home businesses, small offices, retail spaces and classroom settings. With a BD Series, adding value and appeal to items like phone covers, cosmetic cases, fashion accessories, sports memorabilia, gifts, bottles and more is a breeze.

Welcome to a new world of creative possibilities.

Specifications:

		BD-8	BD-12
Printing Method		Piezo ink-jet method
Attachable objects to be printed on	Width	Max. 240 mm (9.4 in.)	Max. 335 mm (13.1 in.)
	Length	Max. 178 mm (7 in.)	Max. 240 mm (9.4 in.)
	Thickness	Max. 102 mm (4 in.)
	Weight	Max. 3 kg (6.6 lb.)	Max. 5 kg (11 lb.)
Maximum printing width/printing length		Max. 210 mm × 148 mm (8.2 in. × 5.8 in.)	Max. 305 mm × 210 mm (12 in. × 8.2 in.)
Ink	Type	ECO-UV (EUV5) 220 ml cartridge
Ink	Colours	Five colours (cyan, magenta, yellow, black, and white) and primer or gloss
Ink-curing unit		Built-in UV-LED lamp
Printing resolution (dots per inch)		Max. 1,440 dpi
Connectivity		Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function		Automatic sleep feature
Rated input		100-240 Va.c. 50 / 60 Hz 1.1A	100-240 Va.c. 50 / 60 Hz 1.2A
Power consumption	During operation	Approx. 90 W	Approx. 100 W
Power consumption	Sleep mode	Approx. 30 W	Approx. 40 W
Acoustic noise level	During operation	59 dB (A) or less	60 dB (A) or less
Acoustic noise level	During standby	52 dB (A) or less	55 dB (A) or less
Dimensions (Width x Depth x Height)		768 mm × 586 mm × 580 mm (30.3 in. × 23.1 in. × 22.9 in.)	995 mm × 710 mm × 583 mm (39.2 in. × 28 in. × 23 in.)
Weight		61 kg (134.5 lb.)	80 kg (177 lb.)
Environment	During operation *1	Temperature: 20°C to 32°C (68°F to 89.6 °F) (22 °C [71.6 °F] or higher recommended) Humidity: 35% RH to 80% RH (no condensation)
Environment	Not operation	Temperature: 5°C to 40 °C (41°F to 104 °F) Humidity: 20% RH to 80% RH (no condensation)
Included Items		Power cord, Cleaning liquid, User's Manual, Software (FlexiDESIGNER VersaSTUDIO Edition, VersaWorks, Roland DG Connect), etc.

To contact Prytec Solutions about Flatbed Printers 102 mm | VersaSTUDIO BD Series use Get a quote.

Welcome to a new world of creative possibilities.

Specifications:

		BD-8	BD-12
Printing Method		Piezo ink-jet method
Attachable objects to be printed on	Width	Max. 240 mm (9.4 in.)	Max. 335 mm (13.1 in.)
	Length	Max. 178 mm (7 in.)	Max. 240 mm (9.4 in.)
	Thickness	Max. 102 mm (4 in.)
	Weight	Max. 3 kg (6.6 lb.)	Max. 5 kg (11 lb.)
Maximum printing width/printing length		Max. 210 mm × 148 mm (8.2 in. × 5.8 in.)	Max. 305 mm × 210 mm (12 in. × 8.2 in.)
Ink	Type	ECO-UV (EUV5) 220 ml cartridge
Ink	Colours	Five colours (cyan, magenta, yellow, black, and white) and primer or gloss
Ink-curing unit		Built-in UV-LED lamp
Printing resolution (dots per inch)		Max. 1,440 dpi
Connectivity		Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function		Automatic sleep feature
Rated input		100-240 Va.c. 50 / 60 Hz 1.1A	100-240 Va.c. 50 / 60 Hz 1.2A
Power consumption	During operation	Approx. 90 W	Approx. 100 W
Power consumption	Sleep mode	Approx. 30 W	Approx. 40 W
Acoustic noise level	During operation	59 dB (A) or less	60 dB (A) or less
Acoustic noise level	During standby	52 dB (A) or less	55 dB (A) or less
Dimensions (Width x Depth x Height)		768 mm × 586 mm × 580 mm (30.3 in. × 23.1 in. × 22.9 in.)	995 mm × 710 mm × 583 mm (39.2 in. × 28 in. × 23 in.)
Weight		61 kg (134.5 lb.)	80 kg (177 lb.)
Environment	During operation *1	Temperature: 20°C to 32°C (68°F to 89.6 °F) (22 °C [71.6 °F] or higher recommended) Humidity: 35% RH to 80% RH (no condensation)
Environment	Not operation	Temperature: 5°C to 40 °C (41°F to 104 °F) Humidity: 20% RH to 80% RH (no condensation)
Included Items		Power cord, Cleaning liquid, User's Manual, Software (FlexiDESIGNER VersaSTUDIO Edition, VersaWorks, Roland DG Connect), etc.

Read less...

To contact Prytec Solutions about Flatbed Printers 102 mm | VersaSTUDIO BD Series use Get a quote.

bdseries-datasheet_das(0.26MB)
