Spider Lifts 20 hp Diesel | Monitor 3710R

Supplier: Monitor

Incredibly light spider lift with huge working height and increased capacity.

Receive 1-3 days from order

Weighing only 5.76 t, the Monitor 3710R Spider Lift is incredibly light for a machine that provides a huge 37 m of working height and with an increased capacity of 250kg. Horizontal outreach is now up to an impressive 13.7 m.

The Monitor 3710R spider lift is a dual power machine, combining a powerful 3 cylinder water cooled Kubota diesel engine with a double-sized battery system. The 3710 is just as at home indoors as outdoors!

Expandable tracks are standard on the 3710 RBDJ making it ideal for sloping ground and other demanding conditions. The new fly-jib design provides an increased working range of 133°.
The 3710 features a new and improved boom design which has a 6-sided section for ultimate strength and stability. It is comprised of seven sections and provides extremely smooth movements and a firm working platform. The boom can be raised and extended simultaneously, helping to reach the required height in the shortest possible time.

Features

•2 Speed Drive

•240 Volt Battery System

•240 Volt Battery System (Optional)

•Air & Water Outlet in Platform (Optional)

•Auto-Level Stabilizer Legs

•Basket Load Control

•Crawler Tracks

•Electric & Air Outlets in Basket

•Electric Controls

•Electric Emergency Lowering System

•Expandable Crawler Tracks

•Fly Jib

•Fully Radio Control Operation (Optional)

•Hydraulic Controls

•Hydraulic Hoses Routed inside booms

•Kubota Diesel Engine (Optional)

•Non-Marking Rubber Tracks

•Platform Rotation

•Radio Control Drive

Specifications:

Max. Working Height:

37.00 m

Max. Working Reach:

13.70 m

Capacity:

250 kg

Chassis Type:

Crawler Tracks

Hydraulic Fly Boom:

Yes

Platform Rotation:

Yes

Weight/Outreach Limited:

Yes

Turret Rotation:

710°

Outrigger Stabilisers:

Yes

Min. Transport Length:

7.44 m

Min. Transport Width:

1.10 m

Min. Transport Height:

1.99 m

Power:

Kubota 20 hp Diesel & Batteries

Weight:

5,760 kg

To contact Monitor about Spider Lifts 20 hp Diesel | Monitor 3710R use Get a quote.
