Spider Lifts 20 hp Diesel | Monitor 2350R Get latest price

Read more...

To contact Monitor about Spider Lifts 20 hp Diesel | Monitor 2350R use Get a quote.

The soft non-marking rubber tracks are very gentle on fragile surfaces. The high quality Danish build coupled with its simple design makes it a great choice for operator satisfaction and long life reliability.

Being only 1.1 m wide, the Monitor 2350R can access many areas that are inaccessible to other machinery. With the dual power (24 volt battery system) option, the 2350R is just as at home indoors. The ability to take such a tall machine inside difficult buildings can open up enormous possibilities and save a lot of time and money compared to resorting to manual labour and scaffolding.

Features

•2-Man Platform

•240 Volt Battery System

•240 Volt Battery System (Optional)

•240 Volt Outlet in Platform

•Air & Water Outlet in Platform

•Auto-Level Stabilizer Legs

•Basket Load Control

•Crawler Tracks

•Electric & Air Outlets in Basket (Air Optional)

•Electric Controls

•Electric Emergency Lowering System (Optional)

•Expandable Crawler Tracks (Optional)

•Fly Jib

•Fully Radio Control Operation (Optional)

•Hydraulic Hoses Routed inside booms

•Kubota Diesel Engine

•Non-Marking Rubber Tracks

•Platform Rotation

•Radio Control Drive

Specifications:

Max. Working Height:

23.10 m

Max. Working Reach:

12.20 m

Capacity:

200 kg

Chassis Type:

Crawler Tracks

Hydraulic Fly Boom:

Yes

Platform Rotation:

Yes

Weight/Outreach Limited:

Yes

Turret Rotation:

710°

Outrigger Stabilisers:

Yes

Min. Transport Length:

5.84 m

Min. Transport Width:

1.09 m

Min. Transport Height:

1.99 m

Power:

Kubota 20 hp Diesel & Batteries

Weight:

3,250 kg

Read less...

To contact Monitor about Spider Lifts 20 hp Diesel | Monitor 2350R use Get a quote.
