Jibbi - Telescopic Tracked Boom Lift 1270 | 12.20 m

Supplier: United Forklift and Access Solutions

Telescopic Tracked Boom Lift 1270 | 12.20 m

The Jibbi 1270 EVO is a telescopic tracked boom lift capable of operating on challenging terrain and slopes of up to 22 degrees.

Receive 1-3 days from order

2m horizontal outreach
Retractable undercarriage
Ideal for all types of terrain
Operate on 22-degree slopes

The Jibbi 1270 EVO is a tracked telescopic boom lift built for tough terrain and slopes up to 22°. It offers 8.2m horizontal outreach, 7m lateral outreach, and a retractable track gauge from 1.95m to 1.15m for tight spaces and easy transport.

Powered by a 19.2hp 3-cylinder diesel engine, it delivers strong performance with reduced emissions. Standard features include joystick controls, safe-lock undercarriage, forklift tyne pockets, and a 3-inch colour display. The detachable basket supports 230kg for two operators, making it perfect for construction, signage, electrical work, painting, and maintenance.

Specifications:

	1270 EVO
Max working height	12.20 m
Max height basket floor	10.20 m
Moving height	8.0 m
Max outreach (load 80 kg)	8.20 m
Max outreach (load 230 kg)	6.50 m
Rotation angle	+ / – 110 °
Basket size	1.80 x 0.70 m
Basket rotation angle	+ / – 70 °
Max basket capacity	230 kg
Length in stowed position (with detached basket)	3.80 (3.0) m
Min width in stowed position	1.15 m
Max working width	1.95 m
Min height in stowed position	1.99 m
Longitudinal levelling	+ / – 15 °
Lateral levelling	+ / – 15 °
Max gradeability	25 °
Max side gradeability	25 °
Drive speed (fast)	2.5 km/h
Security speed	0.3 km/h
Traffic load	4.82 kN/m2
Total weight	3600 kg
Power	14 kW – 19.2 Hp

Standard Equipment

High performance 19.2hp 3-cylinder diesel engine

Retractable undercarriage

Integrated drive system with joystick controls

Automatic Proactive & Dynamic Levelling

Forklift tyne pockets for easy lifting

Undercarriage safe-lock system – Patent Pending

Compact dimensions

Removable basket

3-inch colour display on operator control

Ultrasonic anti-collision system (anti-crush)

Dynamic Work Performance (DWP) – Patent Pending

Options & Accessories

Non-marking tracks

Winch kit 200 kg

Radio remote control

Arctic lubricant for cold climate

Electric pump 220V – 2.2kW / 50 Hz

To contact United Forklift and Access Solutions about Jibbi Telescopic Tracked Boom Lift 1270 | 12.20 m use Get a quote.

2m horizontal outreach
Retractable undercarriage
Ideal for all types of terrain
Operate on 22-degree slopes

Specifications:

	1270 EVO
Max working height	12.20 m
Max height basket floor	10.20 m
Moving height	8.0 m
Max outreach (load 80 kg)	8.20 m
Max outreach (load 230 kg)	6.50 m
Rotation angle	+ / – 110 °
Basket size	1.80 x 0.70 m
Basket rotation angle	+ / – 70 °
Max basket capacity	230 kg
Length in stowed position (with detached basket)	3.80 (3.0) m
Min width in stowed position	1.15 m
Max working width	1.95 m
Min height in stowed position	1.99 m
Longitudinal levelling	+ / – 15 °
Lateral levelling	+ / – 15 °
Max gradeability	25 °
Max side gradeability	25 °
Drive speed (fast)	2.5 km/h
Security speed	0.3 km/h
Traffic load	4.82 kN/m2
Total weight	3600 kg
Power	14 kW – 19.2 Hp

Standard Equipment

High performance 19.2hp 3-cylinder diesel engine

Retractable undercarriage

Integrated drive system with joystick controls

Automatic Proactive & Dynamic Levelling

Forklift tyne pockets for easy lifting

Undercarriage safe-lock system – Patent Pending

Compact dimensions

Removable basket

3-inch colour display on operator control

Ultrasonic anti-collision system (anti-crush)

Dynamic Work Performance (DWP) – Patent Pending

Options & Accessories

Non-marking tracks

Winch kit 200 kg

Radio remote control

Arctic lubricant for cold climate

Electric pump 220V – 2.2kW / 50 Hz

Read less...

To contact United Forklift and Access Solutions about Jibbi Telescopic Tracked Boom Lift 1270 | 12.20 m use Get a quote.

Jibbi-1270-EVO-Brochure-1(4.16MB)
