Athena Bi-levelling Tracked Scissor Lift ...

Athena - Bi-levelling Tracked Scissor Lift 850 | 7.9 m

Supplier: United Forklift and Access Solutions

Bi-levelling Tracked Scissor Lift 850 | 7.9 m

The Athena 850 bi-levelling tracked scissor lift is the world’s most versatile scissor lift. Its unique bi-levelling tracked undercarriage provides the ability to safely manoeuvre and work on the most difficult terrain.

Video for Athena Bi-levelling Tracked Scissor Lift 850 | 7.9 m

Receive 1-3 days from order

2017 “Safety Solution of the Year” Winner at Manufacturers Monthly Endeavour Awards
2016 HRIA & IAPA Best New Access Product Winner
Ideal for all types of terrain
Bi-levelling feature can safely level platform on steep slopes

The Athena 850 is a highly versatile tracked scissor lift with bi-levelling technology, able to safely operate on slopes up to 20° in tight spaces. With a 7.9-metre working height and 250kg lift capacity, it excels on challenging terrain and demanding job sites.

Available in three models—850 BL (Hatz diesel), 850 EVO (Kubota diesel), and 850 Bi-Energy (Hatz diesel + lithium)—it features power-to-platform capabilities, intelligent monitoring, and superior manoeuvrability, ideal for construction, maintenance, signage, agriculture, and more.

Specifications:

	850 BL	850 EVO	850 BI-ENERGY
Basket capacity	250 kg (2 op.)	250 kg (2 op.)	250 kg (2 op.)
Max working height	7.9 m	7.9 m	7.9 m
Max height basket floor	5.9 m	5.9 m	5.9 m
Moving height	6.1 m	6.1 m	6.1 m
Lateral levelling for moving at heights	+ / – 4°	Dynamic Drive System	Dynamic Drive System
Powered Standard	Diesel Hatz 1B40	Diesel Kubota Z482	Lithium-Ion Power Pack / Diesel Hatz 1B40
Accelerator	Automatic	Automatic	–
Undercarriage	Bi-levelling	Bi-levelling	Bi-levelling
Basket levelling	Automatic	Automatic	Automatic
Longitudinal levelling front	+ / – 16°	+ / – 16°	+ / – 16°
Longitudinal levelling rear	+ / – 20°	+ / – 20°	+ / – 20°
Lateral levelling	+ / – 15°	+ / – 15°	+ / – 15°
Power generator (option)	220V – 1kW	220V – 1kW	–
Electric motor (option)	220V – 1kW	220V – 1kW	–
Hydraulic commands	Proportionals	Proportionals	Proportionals
Direction-control system	Yes	Yes	Yes
Easy-drive system	Yes	Yes	Yes
Dynamic Levelling System	–	Yes	Yes
Pro-Active Levelling System	–	Yes	Yes
Kit for high speed	Max 2.20 km/h	Max 2.20 km/h	Max 1.80 km/h
Ground emergency	Yes	Yes	Yes
Control of inclination	Automatic	Automatic	Automatic
Gradeability	25°	25°	25°

To contact United Forklift and Access Solutions about Athena Bi-levelling Tracked Scissor Lift 850 | 7.9 m use Get a quote.

2017 “Safety Solution of the Year” Winner at Manufacturers Monthly Endeavour Awards
2016 HRIA & IAPA Best New Access Product Winner
Ideal for all types of terrain
Bi-levelling feature can safely level platform on steep slopes

Specifications:

	850 BL	850 EVO	850 BI-ENERGY
Basket capacity	250 kg (2 op.)	250 kg (2 op.)	250 kg (2 op.)
Max working height	7.9 m	7.9 m	7.9 m
Max height basket floor	5.9 m	5.9 m	5.9 m
Moving height	6.1 m	6.1 m	6.1 m
Lateral levelling for moving at heights	+ / – 4°	Dynamic Drive System	Dynamic Drive System
Powered Standard	Diesel Hatz 1B40	Diesel Kubota Z482	Lithium-Ion Power Pack / Diesel Hatz 1B40
Accelerator	Automatic	Automatic	–
Undercarriage	Bi-levelling	Bi-levelling	Bi-levelling
Basket levelling	Automatic	Automatic	Automatic
Longitudinal levelling front	+ / – 16°	+ / – 16°	+ / – 16°
Longitudinal levelling rear	+ / – 20°	+ / – 20°	+ / – 20°
Lateral levelling	+ / – 15°	+ / – 15°	+ / – 15°
Power generator (option)	220V – 1kW	220V – 1kW	–
Electric motor (option)	220V – 1kW	220V – 1kW	–
Hydraulic commands	Proportionals	Proportionals	Proportionals
Direction-control system	Yes	Yes	Yes
Easy-drive system	Yes	Yes	Yes
Dynamic Levelling System	–	Yes	Yes
Pro-Active Levelling System	–	Yes	Yes
Kit for high speed	Max 2.20 km/h	Max 2.20 km/h	Max 1.80 km/h
Ground emergency	Yes	Yes	Yes
Control of inclination	Automatic	Automatic	Automatic
Gradeability	25°	25°	25°
