Billennium Tracked Spider Boom Lift B1570 ...

Billennium - Tracked Spider Boom Lift B1570 | 15.00 m

Supplier: United Forklift and Access Solutions

Tracked Spider Boom Lift B1570 | 15.00 m

The B1570 VISUAL ETS is from a line of tracked spider boom lifts, the Billennium series.

Video for Billennium Tracked Spider Boom Lift B1570 | 15.00 m

Receive 1-3 days from order

Advanced self-propelled system
Sturdy outriggers for increased stabilisation
Large, tracked undercarriage for smooth movement
Operate on slopes of up to 10°

The B1570 VISUAL ETS from the Billennium series combines the stability of tracked platforms with the versatility of self-propelled lifts. It handles slopes up to 10° longitudinal and 5° lateral without outriggers and features Adaptive Working Performance for optimized outreach. With an extendable undercarriage for better stability, it offers a 15m working height, 0.79m minimum width, and 2605kg total weight for easy transport. Perfect for maintenance, arboriculture, landscaping, and construction.

Specifications:

	B1570 VISUAL ETS
Max working height	15.0 m
Max height basket floor	13.0 m
Moving height	8.0 m
Max outreach (load 80 kg)	9.6 m
Max outreach (load 140 kg)	8.6 m
Max outreach (load 200 kg)	7.8 m
Max outreach (load 230 kg)	7.5 m
Rotation angle	+ / – 185 °
Basket size	1.4 x 0.74 m
Basket rotation angle	+ / – 70 °
Max basket capacity	230 kg
Length in stowed position (with detached basket)	4.86 m (4.16 m)
Min width in stowed position	0.79 m
Working width on tracks	1.39 m
Min height in stowed position	1.98 m
Longitudinal levelling by SPS	+ / – 10 °
Max lateral inclination with SPS	+ / – 5 °
Max gradeability	20 °
Max side gradeability	+ / – 5 °
Maximum stabilisation area	2.48 m x 4.09 m
Stabilisation	Automatic
Drive speed (fast)	2.5 km / h
Drive speed while at height	0.4 km / h
Non-marking tracks	Yes
Cable remote LED console or display	Yes
ATS, AWP, SPS	Yes
Removable pads	Yes
Total weight	2617 kg
Main power source	Honda iGX390 7.0 kW (9.4 HP) @ 3600 RPM
Hydraulic gearmotors	Yes
Electric gearmotors	No
N°2 battery charger 20Ah-48 V	No

To contact United Forklift and Access Solutions about Billennium Tracked Spider Boom Lift B1570 | 15.00 m use Get a quote.

Advanced self-propelled system
Sturdy outriggers for increased stabilisation
Large, tracked undercarriage for smooth movement
Operate on slopes of up to 10°

Specifications:

	B1570 VISUAL ETS
Max working height	15.0 m
Max height basket floor	13.0 m
Moving height	8.0 m
Max outreach (load 80 kg)	9.6 m
Max outreach (load 140 kg)	8.6 m
Max outreach (load 200 kg)	7.8 m
Max outreach (load 230 kg)	7.5 m
Rotation angle	+ / – 185 °
Basket size	1.4 x 0.74 m
Basket rotation angle	+ / – 70 °
Max basket capacity	230 kg
Length in stowed position (with detached basket)	4.86 m (4.16 m)
Min width in stowed position	0.79 m
Working width on tracks	1.39 m
Min height in stowed position	1.98 m
Longitudinal levelling by SPS	+ / – 10 °
Max lateral inclination with SPS	+ / – 5 °
Max gradeability	20 °
Max side gradeability	+ / – 5 °
Maximum stabilisation area	2.48 m x 4.09 m
Stabilisation	Automatic
Drive speed (fast)	2.5 km / h
Drive speed while at height	0.4 km / h
Non-marking tracks	Yes
Cable remote LED console or display	Yes
ATS, AWP, SPS	Yes
Removable pads	Yes
Total weight	2617 kg
Main power source	Honda iGX390 7.0 kW (9.4 HP) @ 3600 RPM
Hydraulic gearmotors	Yes
Electric gearmotors	No
N°2 battery charger 20Ah-48 V	No

Read less...

To contact United Forklift and Access Solutions about Billennium Tracked Spider Boom Lift B1570 | 15.00 m use Get a quote.
