Haulotte - Electric Articulating Boom Lift SIGMA 16 | 18.76 m

Supplier: United Forklift and Access Solutions

Electric Articulating Boom Lift SIGMA 16 | 18.76 m

The HA20 LE PRO is one of the first of the PULSEO product range, an all-terrain electric articulating boom lift that has a platform height of 18.76 metres and a horizontal outreach of 11.91 metres.

Video for Haulotte Electric Articulating Boom Lift SIGMA 16 | 18.76 m

Receive 1-3 days from order

Large working envelope
Zero tailswing and tight turning circle
Proportional and simultaneous movements
For use indoors and outdoors

The SIGMA 16 is a versatile electric boom lift ideal for indoor and outdoor tasks. It offers a large working envelope, fast lift speed, and smooth proportional controls for maximum efficiency. Equipped with 10 LED spotlights, it ensures excellent visibility and safety on site.

Available in Standard and PRO models, the PRO adds 55° jib rotation for greater flexibility. With zero tailswing, it’s safe to use in tight spaces. Built for operator safety, it includes anti-fall protection, active brake locks, alarms, and more. Perfect for maintenance, finishing, electrical work, and events.

Specifications :

	HA20 LE PRO
Working height	20.76 m
Platform height	18.76 m
Horizontal outreach	11.91 m
Up and over clearance	8.52 m
Lift capacity	250 kg – option 350 kg
Platform size	1.83 x 0.80 m
Length	8.54 m
Width	2.41 m
Height – stowed	2.50 m
Length – storage / transport	6.19 m
Height – storage / transport	3.0 m
Platform rotation	180 ° (+ 90° / – 90°)
Turntable rotation	360 ° continuous
Tailswing	41 cm
Wheelbase	2.5 cm
Ground clearance	46 cm
Tilt	4 °
Proportional drive speed	0.7 – 5 km/h
Gradeability	45 %
Tyres – solid rough terrain	1025 x 365 mm
Turning radius – outside	3.70 m
Weight	9785 kg
Batteries	12 x 6 V – 435 Ah (C20)
Range extender	Kubota, 18.5kW

Standard Equipment

Haulotte Activ’Lighting System

Haulotte Activ’Shield Bar 2.0

Haulotte Activ’Screen

Universal telematics plug

72 V battery pack (435 Ah)

Centralized battery watering system

Battery charge indicator at upper and lower control boxes

Multi-voltage charger (110 – 230 V) and integrated range extender (18.5 kW)

Haulotte Activ’Energy Management: smart battery management system

4-wheel drive: brushless AC motors at each wheel

4-wheel steer

Front oscillating axle

Smooth and proportional movements

Upper control box cover

Tool tray

Large modular platform 2.44 x 0.91 m with lateral swing door entry gate

AC power to platform (110 / 230 V) (option in AUS / NZ)

Swing out engine tray

Sound and light alarm for tilt and load

Travel alarm

Rotating beacon

Options & Accessories

Non-marking tyres

Dual load capacity 250 / 350 kg (standard in AUS / NZ)

Haulotte Activ’Shield Bar 2.0 (standard in AUS / NZ)

Large platform 2.44 x 0.91 m (standard in AUS / NZ)

Side swing door entry gate (standard in AUS / NZ)

Pipe rack kit

Glazier kit

Power to platform 110 / 230 V (female plug in the basket)

Biodegradable hydraulic oil

Cold weather kit

Anti-overspeed kit

Air-line to platform

Flashing light

To contact United Forklift and Access Solutions about Haulotte Electric Articulating Boom Lift SIGMA 16 | 18.76 m use Get a quote.

Large working envelope
Zero tailswing and tight turning circle
Proportional and simultaneous movements
For use indoors and outdoors

Specifications :

	HA20 LE PRO
Working height	20.76 m
Platform height	18.76 m
Horizontal outreach	11.91 m
Up and over clearance	8.52 m
Lift capacity	250 kg – option 350 kg
Platform size	1.83 x 0.80 m
Length	8.54 m
Width	2.41 m
Height – stowed	2.50 m
Length – storage / transport	6.19 m
Height – storage / transport	3.0 m
Platform rotation	180 ° (+ 90° / – 90°)
Turntable rotation	360 ° continuous
Tailswing	41 cm
Wheelbase	2.5 cm
Ground clearance	46 cm
Tilt	4 °
Proportional drive speed	0.7 – 5 km/h
Gradeability	45 %
Tyres – solid rough terrain	1025 x 365 mm
Turning radius – outside	3.70 m
Weight	9785 kg
Batteries	12 x 6 V – 435 Ah (C20)
Range extender	Kubota, 18.5kW

Standard Equipment

Haulotte Activ’Lighting System

Haulotte Activ’Shield Bar 2.0

Haulotte Activ’Screen

Universal telematics plug

72 V battery pack (435 Ah)

Centralized battery watering system

Battery charge indicator at upper and lower control boxes

Multi-voltage charger (110 – 230 V) and integrated range extender (18.5 kW)

Haulotte Activ’Energy Management: smart battery management system

4-wheel drive: brushless AC motors at each wheel

4-wheel steer

Front oscillating axle

Smooth and proportional movements

Upper control box cover

Tool tray

Large modular platform 2.44 x 0.91 m with lateral swing door entry gate

AC power to platform (110 / 230 V) (option in AUS / NZ)

Swing out engine tray

Sound and light alarm for tilt and load

Travel alarm

Rotating beacon

Options & Accessories

Non-marking tyres

Dual load capacity 250 / 350 kg (standard in AUS / NZ)

Haulotte Activ’Shield Bar 2.0 (standard in AUS / NZ)

Large platform 2.44 x 0.91 m (standard in AUS / NZ)

Side swing door entry gate (standard in AUS / NZ)

Pipe rack kit

Glazier kit

Power to platform 110 / 230 V (female plug in the basket)

Biodegradable hydraulic oil

Cold weather kit

Anti-overspeed kit

Air-line to platform

Flashing light
