Haulotte - Diesel Articulating Boom Lift HA26 RTJ PRO | 16 - 28m

Supplier: United Forklift and Access Solutions

Diesel Articulating Boom Lift HA26 RTJ PRO | 16 - 28m

The Haulotte HA26 RTJ PRO diesel articulated boom lift makes no compromises in terms of operator safety, productivity, ease of maintenance and total cost of ownership.

Video for Haulotte Diesel Articulating Boom Lift HA26 RTJ PRO | 16 - 28m

Receive 1-3 days from order

Best in class working envelope
Four simultaneous movements
Four-wheel drive and steer
Front oscillating axle

The HA26 RTJ PRO offers best-in-class performance with a 24.4 m platform height, 17.5 m horizontal outreach, and 9.3 m up-and-over clearance. Featuring 360° rotation, proportional simultaneous movements, and fast lift speeds, it ensures maximum productivity.

Key features include Activ’ Lighting System for safe night loading, Stop Emission System for fuel savings, and Activ’ Screen for easy diagnostics. Built for rough terrain, it’s perfect for construction and outdoor projects.

Specifications :

	HA26 RTJ PRO
Working height	26.4 m
Platform height	24.4 m
Horizontal outreach	17.5 m
Up and over clearance	9.30 m
Lift capacity	250 kg – option 350 kg
Platform size	2.44 x 0.91 m
Length – stowed	11.80 m
Width	2.48 m
Height – stowed	2.97 m
Storage / transport length	9.40 m
Storage / transport height	2.98 m
Platform rotation	180 °
Vertical jib rotation	133 ° (-65 ° / + 68 °)
Turntable rotation	360 ° continuous
Tailswing	0.76 m
Wheelbase	2.80 m
Ground clearance	48 cm
Tilt	4 °
Drive speed	5 km/h
Maximum wind speed rating	45 km/h
Gradeability	45 %
Turning radius – outside	4.35 m
Tyres – solid rough terrain	1025 x 365 mm
Power source	Kubota, 36.5 kW (49.6 hp)
Weight	15,500kg

Standard Equipment

Haulotte Activ’Screen: embedded diagnostic system on lower control box, with colour screen

Haulotte Activ’Shield Bar 2.0

Haulotte Activ’Lighting System, safe load

Haulotte Stop Emission System: automatic engine stop system

Universal telematics plug

4-wheel drive, 4-wheel steer

Front oscillating axle

4 simultaneous movements

Automatic differential wheel lock

Upper control box cover

Tool tray

Large modular Haulotte basket 2.44 m x 0.91 m

Lateral swing door entry gate

AC power to platform (110 / 230 V)

Swing out engine tray

Sound and light alarm for tilt and load

Rotating beacon

Travel alarm

Electric pump system and emergency descent

12 V battery / electrical control system

Engine pre-heater with light indicator

Low fuel level indicator (upper control box), fuel gauge (lower control box)

Options & Accessories

60 km/h wind speed

Power to platform (female plug in the basket)

Air-line to platform

Drop bar entry gate

Biodegradable hydraulic oil

Hydraulic oil cooler

Cold weather kit – 20 °C / arctic weather kit – 25 °C

Pipe cradle pack

Glazier pack

Working light

Battery circuit breaker

To contact United Forklift and Access Solutions about Haulotte Diesel Articulating Boom Lift HA26 RTJ PRO | 16 - 28m use Get a quote.

Best in class working envelope
Four simultaneous movements
Four-wheel drive and steer
Front oscillating axle

Specifications :

	HA26 RTJ PRO
Working height	26.4 m
Platform height	24.4 m
Horizontal outreach	17.5 m
Up and over clearance	9.30 m
Lift capacity	250 kg – option 350 kg
Platform size	2.44 x 0.91 m
Length – stowed	11.80 m
Width	2.48 m
Height – stowed	2.97 m
Storage / transport length	9.40 m
Storage / transport height	2.98 m
Platform rotation	180 °
Vertical jib rotation	133 ° (-65 ° / + 68 °)
Turntable rotation	360 ° continuous
Tailswing	0.76 m
Wheelbase	2.80 m
Ground clearance	48 cm
Tilt	4 °
Drive speed	5 km/h
Maximum wind speed rating	45 km/h
Gradeability	45 %
Turning radius – outside	4.35 m
Tyres – solid rough terrain	1025 x 365 mm
Power source	Kubota, 36.5 kW (49.6 hp)
Weight	15,500kg

Standard Equipment

Haulotte Activ’Screen: embedded diagnostic system on lower control box, with colour screen

Haulotte Activ’Shield Bar 2.0

Haulotte Activ’Lighting System, safe load

Haulotte Stop Emission System: automatic engine stop system

Universal telematics plug

4-wheel drive, 4-wheel steer

Front oscillating axle

4 simultaneous movements

Automatic differential wheel lock

Upper control box cover

Tool tray

Large modular Haulotte basket 2.44 m x 0.91 m

Lateral swing door entry gate

AC power to platform (110 / 230 V)

Swing out engine tray

Sound and light alarm for tilt and load

Rotating beacon

Travel alarm

Electric pump system and emergency descent

12 V battery / electrical control system

Engine pre-heater with light indicator

Low fuel level indicator (upper control box), fuel gauge (lower control box)

Options & Accessories

60 km/h wind speed

Power to platform (female plug in the basket)

Air-line to platform

Drop bar entry gate

Biodegradable hydraulic oil

Hydraulic oil cooler

Cold weather kit – 20 °C / arctic weather kit – 25 °C

Pipe cradle pack

Glazier pack

Working light

Battery circuit breaker
