LED Digital Screen INDOOR IP 34 | IE SERIES ...

LED Digital Screen INDOOR IP 34 | IE SERIES

Supplier: SAS Supplier Group

LED Digital Screens are customisable products that can be made to cater to your specific project needs.

Digital Signage, Digital Displays,

Receive 1-3 days from order

Features:

Easy Installation & Easy Maintanence
Energy Efficient
High Definition Display
High Brightness
Wifi Wireless Control

Specifications IE SERIES:

Model No.
- IE161
Pixel Pitch (mm)
- 1.875
LED Configuration
- SMD1515
Module Resolution (dots)
- 128x128
Module Size (WxH) (mm)
- 240 x 240
Pixel Density (dots/m3)
- 284444
Panel Dimension (WxHxD) (mm)
- 480 x 480 x 65
Panel Resolution (HxV)
- 256x256
Max. Brightness (nits)
- 1000nits-2500nits or higher
Net Weight per panel (kg)
- 5.0kg
Avg Power Consumption (W/m2)
- 200
Max Power Consumption (W/m3)
- 600
Viewing Angle (H/V)
- 160°/160°
Refresh rate
- 23840HZ
Colour Processing (bit)
- 13-18bit
Driving Mode (Scan)
- 1/32
Frame Material
- Die Casting Aluminium
Operational Temp/Humidity
- -20°-50°C, 10-90% RH -4"-122" F, 10-90% RH
- 4-122°F, 10-90% RH
IP Rating
- Indoor IP 34
Maintenance Method
- Front & Rear

Model No.
- IE251
Pixel Pitch (mm)
- 25
LED Configuration
- SMD2020
Module Resolution (dots)
- 96x96
Module Size (WxH) (mm)
- 240 x 240
Pixel Density (dots/m3)
- 160000
Panel Dimension (WxHxD) (mm)
- 480 x 480 x 65
Panel Resolution (HxV)
- 192 x 192
Max. Brightness (nits)
- 1000nits-2500nits or higher
Net Weight per panel (kg)
- 5.0kg
Avg Power Consumption (W/m2)
- 170
Max Power Consumption (W/m3)
- 520
Viewing Angle (H/V)
- 160°/160°
Refresh rate
- 23840HZ
Colour Processing (bit)
- 13-16bit
Driving Mode (Scan)
- 1/32
Frame Material
- Die Casting Aluminium
Operational Temp/Humidity
- -20°-50°C, 10-90% RH -4"-122" F, 10-90% RH
- 4-122°F, 10-90% RH
IP Rating
- Indoor IP 34
Maintenance Method
- Front & Rear

To contact SAS Supplier Group about LED Digital Screen INDOOR IP 34 | IE SERIES use Get a quote.
