Equipped with our patented particle control system (PCS®), this machine offers operators complete control of the particle size being blasted to fine-tune their blasting parameters for each unique application.

From 0.3mm to 3.0mm, and every tenth of a millimeter between, this machine allows operators to select from 1 of 28 particle sizes to dial in their blasting parameters for optimal performance.

Blasting a delicate surface? Select a smaller particle size, say 0.4mm, and blast at a lower pressure.

Looking to remove stubborn contaminant? Select a larger particle size, say 2.8mm, and blast at a higher pressure.

With a 7” LCD screen and digital controls, the PCS ULTRA provides an intuitive display that allows the user to easily view and adjust blasting parameters and machine settings.

The machine also features programmable application recipes, which allows users to set and save blasting parameters, such as blast pressure, particle size and feed rate. Lastly, the PCS ULTRA introduces our patent-pending defrost cycle for moisture control, core cleaning, and increased machine uptime.

The PCS ULTRA is IoT enabled via Cold Jet’s Industry 4.0 solution, Cold Jet CONNECT®. The system provides remote monitoring and diagnostics, training videos, machine documentation, and self-guided troubleshooting at your fingertips. Should more assistance be required, operators can quickly and easily connect with Cold Jet service technicians via chat, service tickets or voice and video call.

The Aero2 ULTRA Series Advantage

SureFlow Feeder System

Our patented SureFlow Feeder System incorporates thumpers, ramrods, vibrators, and an insulated hopper, providing optimal hopper agitation for a consistent flow of dry ice.

New Motors, Gearboxes, and Cabling

The new motor array is built with ultra-cold temperature motors that keep working even after long blasting cycles. Proprietary control firmware and motor drivers get the most efficient and optimal power from these motors.

Core Contamination Control

Dust and debris are no match to our new core contamination control system, providing protection to core components and minimizing routine maintenance.

Patent-Pending Defrost Cycle

Our industry-first, patent-pending defrost cycle can be engaged automatically or manually and helps to reduce machine downtime in the event internal components freeze or clog.

Intuitive Display

Easily view and control blasting parameters and machine settings on 7" LCD color screen.

Programmable Application Recipes

Set and save application recipes (blast pressure, particle size, feed rate). Ensure the most efficient use of consumables and prevent user error.

Industry Changing Performance

Consistent and pulse-free blast stream.

Complete Control

No other machine offers this level of precision and versatility.

Lower Noise Levels

Cleans effectively at lower air and blast pressures.

Ergonomic

Optimized design and combination of materials leads to weight and size reduction. Redesigned blast hoses for flexibility and durability.

IoT Capability

Remote monitoring and diagnostics with industry-first Cold Jet CONNECT.

Aero2 PCS ULTRA Features

• Particle Control® system: 28 particle sizes (0.3mm – 3.0mm) for greater versatility
• 7” LCD display screen with digital controls
• Streamlined “straight-through” air system
• Programmable Application Recipes
• Advanced Aerodynamic Low Load Airlock Feeder
• Patented High-Efficiency Flow Initiation Regulator
• Patented Advanced Direct Drive Feeding System
• Patent-pending defrost cycle
• Core contamination control system
• New state-of-the-art motors, gearboxes, and cabling
• Coated tool grade aluminum alloy, stainless steel and polymer frame
• Designed for mobility and maneuverability
• IoT Capability – Cold Jet CONNECT
• Integration and automation ready

Aero2 PCS ULTRA Specifications

Dimensions

38.5 in (98 cm) x 19 in (48 cm) x 45 in (114 cm)

Weight

266 lb (120.6 kg)

Hopper Capacity

60 lb (27 kg)

Display

7” LCD Screen

Power Requirements

110/220 VAC (50/60 Hz); AMPS: 4.5

Variable Feed Rate

0 - 4 lb/min (0 - 1.8 kg/min)

Dry Ice Particle Size

Input: 3mm ; Output: 0.3 - 3.0mm

Blast Pressure Range

20 - 145 psi (1.4 - 10 bar)

Supply Pressure Range

40 - 145 psi (2.8 - 10 bar)

Nozzle Air Consumption Range

12 - 100 cfm at 80 psi (0.3 - 2.8 m3/min at 5.5 bar)

Air Flow Path

3/4 in (19mm) Straight Through Tubing

SureFlow

Thumper, Ramrods, Electric Vibrator, “Always-On” Hopper Agitation, Isolated Hopper
