This compact unit fits seamlessly into any dry ice production facility. It captures CO2 gas emitted during standard dry ice production, converts it back into liquid form, and recycles it to create more dry ice.

Cold Jet’s R&D team has revolutionized small-scale recovery systems. Version 2 enhances the original design with new features from our engineering team:

Now, your Cold Jet pelletizer and the RE-CO2 320V2 communicate seamlessly. You can start and operate the recovery system directly from your pelletizer’s control panel.

For large-scale dry ice production with multiple RE-CO2 320V2 units, our intelligent system optimizes CO2 gas flow to maximize efficiency.

Experience peak performance across connections, electrical systems, motors, cooling, oil management, and buffer tank. Discover all the benefits of this smart, reliable, and eco-friendly CO2 recovery system.

Advantage:

An Extra Layer of Sustainability

The RE-CO2 320V2 can capture your operation's waste carbon dioxide, transforming it into a valuable resource for your dry ice production.

Boost Production Efficiency

Designed to minimize liquid CO2 waste, the RE-CO2 320V2 significantly improves the efficiency of your dry ice production process.

Dramatic Savings on Liquid CO2 Costs

Double your CO2 investment! Our recovery system can reduce your annual liquid CO2 costs by up to 40%. Reinvest these savings to grow your business.

Produce More Dry Ice with Less

Increase your dry ice output by up to 70% without consuming extra liquid CO2. The RE-CO2 320V2 delivers exceptional performance.

Smart, Scalable, and Simple

Our plug-and-play system is easily controlled from your pelletizer's HMI screen. The modular design of the RE-CO2 320V2 makes it adaptable for operations of any size. Focus on your business while our system optimizes your CO2 usage.

Compact and Efficient

The Cold Jet CO2 reclaimer is exceptionally compact compared to other options on the market. It's a custom-engineered solution tailored to your specific needs.

Features

• Redesigned buffer tank frame and cover for optimal CO2 gas flow
• Enhanced connections for valve control and CO2 handling
• Electrical cabinet with superheat controller
• 24 V DC coils
• Additional temperature sensors
• Convenient access plugs for warm weather conditions
• Durable, high-quality cooling fans
• Claw coupling motors
• Liquid receiver for refrigerant with added bypass valve for compressor cooling
• Upgraded two-stage oil separator
• Oil regulator

Specifications

Liquefaction Capacity

Up to 705.4 lbs/hr (320 kg/hr)

Dimensions (L x W x H)

107 x 52 x 147.7 in (2718 x 1320 x 3751 mm)

Height Without Buffer Tank

89 in (2259 mm)

Unit Weight*

4795 lbs (2175 kg) * Without Buffer Tank

Buffer Tank Weight

717 lbs (325 kg)

Unit Shipping Weight

5864 lbs (2660 kg)

Buffer Tank Shipping Weight

1292 lbs (586 kg)

Voltage & Frequency

440 - 480 V AC, 60 Hz or 400 V AC, 50 Hz

Power

50 kWh

Current

85A

Power Connection

85A / 3P + GND/PE

Refrigerant

POE32 oil

Food Grade Compressor Oil Type

PAO68 oil (Food Grade)

Min to Max Temperature

5°C (41°F) to 30°C (86°F)

Noise Level

85 dB. Max
