Control Valve | Mark 75PTP Series Get latest price

The Mark 75PTP is a Mark 75 wafer style control valve with an 80mm stainless steel piston actuator. The Gemu cPOS smart positioner is standard and required for control applications. For on/off service, the valve may be supplied without a positioner. The JVCV should be used for sizing selection. The “T” slot design connection allows for quick and easy reversing of function – from reverse acting to direct acting (or vice versa).

Features & Benefits

• Great capacity in a compact, wafer style body
• 2″ Mark 75PTP provides 72 Cv (62 Kv)
• JVCV should be used for sizing selection

Specifications

• Sizes: 1″ – 2″ (DN25 – DN50)
• Body Material: Stainless Steel, Carbon Steel
• Max Pressure Drop: 125 psi (8,6 bar) with standard piston actuator and spring
• Ranges: 1″: 12.7 – 14.7 psi (0,88 – 1,01 bar); 1-1/2″: 12.7 – 16.7 psi (0,88 – 1,15 bar); 2″: 12.7 – 19.1 PSI (0,88 – 1,32 bar)
• Turndown Ratio: 100:1
• Shutoff: ANSI Class IV tightness

To contact Cebeco about Control Valve | Mark 75PTP Series use Get a quote.
