Lift-Truk Order Picking and Access Platforms Get latest price

Ensuring a more profitable and efficient workplace, these devices are ergonomically designed and user-friendly. Pick, lower and transport items weighing up to 60 kg with ease and reduce handling time or need for extra labour.

Designed as a mobile platform with a lift, the Lift-Truk is quick to raise, lower and stock heavy products in one seamless action. Furthermore, the entire stock picking process can be handled by one person. Goods are placed on the lift table and either lowered/raised according to the application. The operation is similar to a forklift, however, this unique device acts as a trolley as well.

This platform ladder is suited to retail stores, warehouses and similar stock loading/unloading applications. It’s completely Australian Made and works best on levelled operating surfaces.



The Lift-Truk grants fast, low-risk stock picking!

Eliminate dangerous manual handling risks with this safe access solution. No longer will employees have to carry large items up or down a ladder. The Lift-Truk utilises a winding mechanism, similar to that of a forklift, and positions items at the exact shelf height. This allows users to simply transfer to their desired location. Additionally, the platform can be lowered as required. All in all, it saves time during the unloading and loading process and reduces the need for a trolley as the ladder can perform both duties.

The whole stock picking process can be handled by one person removing the need for a second person to pass items up or down. Featuring a reliable manually operated winch, maintenance costs are minimal, and there is no downtime for charging of batteries.

Standard Features:

• Auto-safe manual order picking platform ladder.
• Designed and tested to a 150 kg load rating.
• Lifts, lowers and transports items weighing up to 60 kg.
• Manually operated winch.
• Reduces handling time.
• Reduces extra labour or equipment needed to complete the task.
• Reduces maintenance downtime.
• Reduces potential accidents or manual handling injuries.
• Costs less than other products that deliver similar benefits.
• Australian Made.
• Meets Australian, New Zealand, United States and European Union Standards.





Additional Extras:

Upgrade your model to a Lift-Truk PRO and protect employees from accidentally stepping off the front of the platform with additional yellow powder-coated rails.

Auto-Gate Operation



Also, the fully automatic Auto-Gate can be equipped to protect against the risk of falls. When personnel enters the platform area the gate automatically closes behind. Lastly, the Rota-Gate feature provides a side opening gate-way at the side of the platform creating easy access for stock-picking, inspection and many other tasks. To open or close, the gate is rotated into position.

Rota-Gate Operation



Select the right Lift-Truk model!

The primary function of the Lift-Truk is for picking and shelf stocking. It can be moved in any direction to maximise the speed in delivery of these related applications. The maximum recommended storage height for an item is dependent on its weight and the working range of the selected product. The maximum load rating is 60 kg.

To operate most effectively, the Lift-Truk requires a smooth and level surface. When mobile, the feet of the device clear an operating surface by approximately 20 mm. Typically a concrete slab floor provides a suitable operating surface, however, areas around sumps, drains and other variations that exceed 20 mm will not permit safe use. This platform ladder features good movability and can be used in confined spaces. Before using, check for doorway height, overhead fixtures, space turning at the end of storage bays and space for movement in aisles or between machinery and furniture.

Lift-Truk Size Selection Chart:

Stock Code	Platform Height (mm)	Working Range up to 5 kg item From – To (m)	Working Range up to 20 kg item  From – To (m)
SSMN4LT	1145	1.4 – 2.8	1.4 – 2.3
SSMN5LT	1435	1.7 – 3.1	1.7 – 2.6
SSMN6LT	1720	2.0 – 3.4	2.0 – 2.9
SSMN7LT	2005	2.3 – 3.7	2.3 – 3.2
SSMN8LT	2295	2.5 – 3.9	2.5 – 3.4
SSMN9LT	2580	2.8 – 4.2	2.8 – 3.7
SSMN10LT	2865	3.1 – 4.5	3.1 – 4.0
SSMN11LT	3155	3.4 – 4.8	3.4 – 4.2
SSMN12LT	3440	3.7 – 5.1	3.7 – 4.6
SSMN13LT	3735	4.0 – 5.4	4.0 – 4.9
SSMN14LT	4015	4.3 – 5.7	4.3 – 5.2

Lift-Truk Dimensions:

Model	A	B	C	D	E
SSMN4LT	1145	755	1765	1510	550
SSMN5LT	1435	792	1895	1795	550
SSMN6LT	1720	835	2025	2085	550
SSMN7LT	2005	875	2155	2370	550
SSMN8LT	2295	915	2285	2655	550
SSMN9LT	2580	955	2415	2945	550
SSMN10LT	2865	995	2545	3230	550
SSMN11LT	3155	1035	2675	3515	550
SSMN12LT	3440	1075	2805	3805	550
SSMN13LT	3725	1115	2935	4090	550
SSMN14LT	4015	1155	3105	4375	550
Note: All dimensions are in mm
