HIKMICRO - Professional Thermal Imaging Camera - 480 x 360 | SP40 Get latest price

Read more...

To contact Testrix about HIKMICRO Professional Thermal Imaging Camera - 480 x 360 | SP40 use Get a quote.

The HIKMICRO SP40 Thermal Imaging Camera is a high-performance handheld tool built for professional electrical, mechanical, building, and industrial inspections. Featuring a 480 × 360 infrared resolution sensor, optional high-temperature measurement up to 2200°C, and advanced onboard analysis tools, the SP40 delivers unmatched clarity and precision for demanding inspection environments.

Whether you are performing preventive maintenance, HVAC diagnostics, or industrial quality assurance, the SP40 allows you to detect and resolve issues with accuracy, improving safety, reducing downtime, and increasing operational efficiency.

Key Features

• Infrared resolution: 480 × 360 (172,800 pixels) with Super IR enhancement to 960 × 720 (691,200 pixels)
• Thermal sensitivity (NETD): < 0.03°C @ 30°C (30 mK)
• Temperature range: -20°C to 650°C (expandable to 2200°C with optional lens)
• Laser-assisted autofocus with 12× digital zoom
• AI-based analysis: Area and point measurement, isotherm detection, hot/cold spot markers, alarms
• Radiometric imaging and video recording (JPEG/MP4 with full pixel temperature data)
• 5” HD capacitive touchscreen display (1280 × 720 resolution)
• Connectivity: Wi-Fi, Bluetooth, USB-C, HDMI for fast data transfer and live streaming
• Storage: 128 GB removable SD card for images and video
• Rugged IP54-rated housing, drop-tested to 1 m
• Battery life: Up to 4 hours per battery (2 included)

Applications

• Electrical inspections: Overheating connections, breakers, and switchgear
• Mechanical diagnostics: Bearings, motors, pumps, gears
• Building and HVAC inspections: Insulation defects, air leaks, moisture intrusion, ductwork issues
• Industrial process monitoring: Boilers, furnaces, pipelines, and high-heat environments
• Emergency response (optional settings): Firefighting and rescue applications with hotspot visualization

Benefits

• High-resolution infrared imaging with Super IR enhancement
• Laser autofocus and touchscreen for fast, precise operation
• Radiometric video recording for advanced reporting and analysis
• Industrial-grade durability with ergonomic, lightweight design
• Flexible connectivity for real-time sharing and reporting

Technical Specifications

Infrared Resolution: 480 × 360 (Super IR: 960 × 720)

NETD: < 0.03°C (30 mK)

Temperature Range: -20°C to 650°C (up to 2200°C with optional lens)

Accuracy: ±2°C or ±2%

Display: 5” HD touchscreen, 1280 × 720

Focus: Laser-assisted autofocus

Zoom: 1.0× – 12.0× digital zoom

Image Modes: Thermal, Visual, Fusion, Blending, PIP

Storage: 128 GB removable SD card

Video Format: MP4 with radiometric data

Connectivity: Wi-Fi, Bluetooth, USB-C, HDMI

Battery Life: Up to 4 hours per battery (dual pack included)

Protection Rating: IP54, 1 m drop-tested

Weight: Approx. 1451 g with battery

Package Includes

• HIKMICRO SP40 Thermal Imaging Camera
• 2 × rechargeable batteries and charger
• USB-C cable
• HDMI cable
• Hard carry case
• Calibration certificate
• Quick start guide
• HIKMICRO Analysis software (download)

Why Choose the HIKMICRO SP40?

The SP40 combines class-leading thermal resolution, advanced analysis tools, and rugged durability in a professional-grade design. With wireless connectivity, radiometric video capture, and optional high-temperature capability up to 2200°C, it is the ideal inspection camera for industrial, electrical, and building professionals who demand precision and reliability.
