Enerpat - Vertical Hammer Mill Electronic Waste Shredder | V Series

Supplier: Enerpat Group

Vertical Hammer Mill Electronic Waste Shredder | V Series

An advanced electronic waste shredder designed for efficient recycling of e-waste, the vertical hammer mill shredder processes items such as computers, appliances and fridges for effective material recovery.

Video for Enerpat Vertical Hammer Mill Electronic Waste Shredder | V Series

Delivers efficient, high-throughput shredding with clean separation for superior e-waste metal recovery.

Reliable, Efficient E-Waste & Scrap Metal Processing

The vertical hammer mill shredder is engineered to efficiently crush and grind discarded electronics including computers, small household appliances, televisions, and refrigerators. This provides consistent chip fragment sizes, ideal for downstream material separation and enhanced metal recovery, establishing an advanced solution for profitable e-waste recycling operations.

Key Features

High efficiency crushing: High manganese, wear-resistant hammers maintain exceptional throughput across mixed feedstocks.
Clean finish grinding: Advanced cutter system achieves sharp, uniform breaks for clean metal surfaces, enabling rapid separation.
Simple upkeep: Compact design and accessible service points reduce maintenance times and costs.
Operator safety: Multiple guards, sensors, and lockouts to meet stringent safety standards.

Operation Principles

Feed: Scrap metal is conveyed into the crushing chamber via automatic or manual systems.
Crushing & Grinding: The upper chamber hammers crush material, then grind it between steel knives and a wear-resistant liner.
Discharge: Metal particles (50–80 mm) pass through calibrated gaps to the discharge chamber, expelled by an integrated scraper.

Technical Specifications

Model	Main Motor Power (kW)	Speed (rpm)	No. of Rolling Knives	Dimensions (mm)	Weight (t)
V1500	132	670	36	3294 × 780 × 5014	14

Construction & Components

Ultra-Wear-Resistant Housing: Advanced welding and split design for exceptional durability and simplified maintenance.
High-Toughness Hammers: Steel castings, heat-treated with long life and resistance to impact and abrasion.
Power System: Equipped with German Siemens motor, heavy-duty pulleys, and hydraulic coupler for reliable, efficient output.
Bearings: German FAG/SKF bearings with self-aligning, shock-absorbing load protection to extend service life.
Intelligent Control: Siemens/Schneider PLC with touch screen for one-touch start and automatic feed adjustment.

Applications

Electronic waste (e-waste): computers, appliances, televisions
Fridges and small household appliances
Mixed metal scrap requiring fragmenting for material recovery

To contact Enerpat Group about Enerpat Vertical Hammer Mill Electronic Waste Shredder | V Series use Get a quote.
