Automation Controller 4 PTP axes | NX102-9000 ...

Automation Controller 4 PTP axes | NX102-9000 Price Guide: $3,965

Supplier: Omron Automation & Robotics

Automation Controller 4 PTP axes | NX102-9000

Automation Controller 4 PTP axes | NX102-9000

Automation Controller 4 PTP axes | NX102-9000

Sysmac NX1 Modular CPU, 5MB program and 33.5MB data memory , built-in EtherCAT (0 servo axes, 4 PTP axes, total 64 EtherCAT nodes), 2 Ethernet ports (OPC-UA and EtherNet/IP) “Disclaimer: NX-PF cards typically required for IO expansion. Sold separa

Receive 1-3 days from order

Specifications:

Max. numeric of axes (incl. virtual) 4
Max. numeric of expansion units 32
Max. numeric of PTP axes 4
Max. numeric of remote I/O nodes 64
Primary task cycle time 1 ms
Program memory 5 MB
Variables memory 33.5 MB
Supports AI control No
Supports DB connection No
Supports motion control No
Supports OPC-UA Yes
Supports position control Yes
Supports sequence control Yes
Communication option(s) Serial RS-232C,Serial RS-422,Serial RS-485
Communication port(s) EtherCAT Master, EtherNet/IP, Ethernet TCP/IP, USB
Controller functionality Position control, Sequence control, OPC-UA
I/O system NX I/O Bus

To contact Omron Automation & Robotics about Automation Controller 4 PTP axes | NX102-9000 use Get a quote.

Specifications:

Max. numeric of axes (incl. virtual) 4
Max. numeric of expansion units 32
Max. numeric of PTP axes 4
Max. numeric of remote I/O nodes 64
Primary task cycle time 1 ms
Program memory 5 MB
Variables memory 33.5 MB
Supports AI control No
Supports DB connection No
Supports motion control No
Supports OPC-UA Yes
Supports position control Yes
Supports sequence control Yes
Communication option(s) Serial RS-232C,Serial RS-422,Serial RS-485
Communication port(s) EtherCAT Master, EtherNet/IP, Ethernet TCP/IP, USB
Controller functionality Position control, Sequence control, OPC-UA
I/O system NX I/O Bus

To contact Omron Automation & Robotics about Automation Controller 4 PTP axes | NX102-9000 use Get a quote.
