Self Loading Concrete Mixer 74 kW | L4700 T

Supplier: Dieci Australia

The L 4700 T (without self loading) is a medium-high model of the Dieci Truck Mixers specifically designed for heavy and intensive use.

Receive 1-3 days from order

This model is equipped with a self-locking rear axle, servo- controlled 2 speed gearbox, hydrostatic transmission, 4 driving and steering wheels with braking on all, oil-bath disc brakes, discharge chute adjustable in height and with 180° rotation.

Specifications:

Max Capacity: 3.5 m³
Total Weight: 6,700 kg
Max Power: 74 kW (99 hp)
Engine Brand: FPT

Technical Specifications:

Dimensions

Length: 5,520 mm
Width: 2,400 mm
Height: 3,140 mm

Performance

Concrete yield: 3.5 m3
Maximum speed: 23 km/h
Water tank capacity: 630 l

Mass

Unladen weight: 6,700 kg

Engine

Brand: FPT
Fuelling: Diesel
Displacement: 4,485 cm³
Nominal power: 74 kW (99 hp)
RPM at nominal power: 2,200 rpm
Emission standard: Stage IIIA/Tier 3

Transmission

Transmission type: Hydrostatic with variable displacement pump

Tyres

Standard tyres: 405/70×20″

To contact Dieci Australia about Self Loading Concrete Mixer 74 kW | L4700 T use Get a quote.

Specifications:

Max Capacity: 3.5 m³
Total Weight: 6,700 kg
Max Power: 74 kW (99 hp)
Engine Brand: FPT

Technical Specifications:

Dimensions

Length: 5,520 mm
Width: 2,400 mm
Height: 3,140 mm

Performance

Concrete yield: 3.5 m3
Maximum speed: 23 km/h
Water tank capacity: 630 l

Mass

Unladen weight: 6,700 kg

Engine

Brand: FPT
Fuelling: Diesel
Displacement: 4,485 cm³
Nominal power: 74 kW (99 hp)
RPM at nominal power: 2,200 rpm
Emission standard: Stage IIIA/Tier 3

Transmission

Transmission type: Hydrostatic with variable displacement pump

Tyres

Standard tyres: 405/70×20″

Read less...

To contact Dieci Australia about Self Loading Concrete Mixer 74 kW | L4700 T use Get a quote.
