SANY - SY155U - Excavator 16T Get latest price

Read more...

To contact WATM Equipment about SANY SY155U - Excavator 16T use Get a quote.

• Displacement

  3 L
  Engine model

  Isuzu AR-4JJ1XASC
  Rated power

  78.5kW/1900rpm
  OPERATION RANGE
  Max. digging depth

  5468 mm
  Max. digging height

  9218 mm
  Max. digging reach

  8338 mm
  Max. dumping height

  6756 mm
  Max. vertical digging depth

  3796 mm
  Min. swing radius

  2086 mm
  Operating weight

  16,000 kg
  DIMENSIONS
  Blade height

  490 mm
  Min. ground clearance

  425 mm
  Tail swing radius

  1500 mm
  Track length

  3665 mm
  Transport height

  2820 mm
  Transport length

  8178 mm
  Transport width

  2590 mm
  Upper width

  2490 mm
  UNDERCARRIAGE/WORKING DEVICE
  Arm length

  2500 mm
  Boom length

  4600 mm
  Track gauge

  1990 mm
  Track width

  3665 mm
  PERFORMANCE
  Arm digging force

  67.0 kN
  Bucket digging force

  103.0 kN
  Cooling system

  16 L
  Engine oil

  15 L
  Fuel tank capacity

  210.0 L
  Gradeability

  35°
  Ground pressure

  41.0 kPa
  Hydraulic tank capacity

  110.0 L
  Swing speed

  12 rpm
  Travel speed

  3.1/5.3 km/hr
  HYDRAULIC SYSTEM
  Hydraulic motors – swing

  12 rpm
  Main pump – maximum flow

  252.0 L/min

Read less...
