Roland DG Large Format Printer Machine ...

Roland DG - Large Format Printer Machine 110 W | GR2 Vinyl Cutters

Supplier: Prytec Solutions

Large Format Printer Machine 110 W | GR2 Vinyl Cutters

The GR2 series of large-format cutting plotters from Roland DG is designed to integrate effortlessly into your print-then-cut workflow, ensuring fast and precise results.

Receive 1-3 days from order

Now is the time to grow your business by offering a greater range of products and a faster, more reliable service. The GR2 series of large format cutting plotters from Roland DG is built to fit seamlessly with your print then- cut workflow and deliver fast, flawless results from day one.

Specifications:

Model		GR2-640	GR2-540
Drive system Cutting mechanism		Digital control servo motor Media-moving method
Acceptable material size (1)(2)
	Width:	Max. 70.1 in. (1,782 mm) Min. 1.97 in. (50 mm)	Max. 62.7 in. (1,594 mm) Min. 1.97 in. (50 mm)
	Thickness:	Thickness including backing paper is 0.8 mm (31.4 mil.) or less
	Roll weight:	52.9 lb. (24 kg)	44.1 lb. (20 kg)
Maximum cutting area		Width: 64 in. (1,627 mm) Length: 1,968 in. (50 m)	Width: 54 in. (1,372 mm) Length: 1,968 in. (50 m)
Usable Tools		CAMM-1 series blade (including blades for flatbed use)
Maximum cutting speed		1.19 to 60 in./s (30 to 1,530 mm/s)
Cutting force		5 – 600 gf
Mechanical resolution		0.236 mil./step (0.006 mm/step)
Software resolution		0.98 mil./step (0.025 mm/step)
Distance accuracy (*3)		Error of less than ±0.1% of distance traveled or 0.254 mm (10 mil.), whichever is greater
Repeatability (3)(4)(*5)		3.94 mil. (0.1 mm) or less
Connectivity		Ethernet (automatic switching between 10BASE-T and 100BASE-TX) USB 2.0 (FULL SPEED compliant) RS-232C
Replot memory		32 MB
Command system		HP-GL, HP-GL/2 compliant
Power requirements		AC 100 to 240 V ± 10%, 50/60 Hz
Power consumption		Approx. 110 W
Acoustic noise level		During operation 56 dB (A) or less During standby 40 dB (A) or less
Dimensions (Width x Depth x Height)		78.1 in. (W) x 30 in. (D) x 44.4 in. (H) 1,982 mm (W) x 756 mm (D) x 1,127 mm (H)	68 in. (W) x 25.7 in. (D) x 44 in. (H) 1,711 mm (W) x 651 mm (D) x 1,111 mm (H)
Weight		214 lb. (97 kg)	133 lb. (60 kg)
Packaging dimensions		87 in. (W) x 15.6 in. (D) x 34.7 in. (H) 2,200 mm (W) x 395 mm (D) x 880 mm (H)	81 in. (W) x 15.6 in. (D) x 33.5 in. (H) 2,040 mm (W) x 395 mm (D) x 850 mm (H)
Packaging weight		214 lb. (97 kg)	188 lb. (85 kg)
Operating environment		Temperature: 15 to 30 °c (59 to 86 °F), Humidity: 25 to 75% RH (no condensation)
Accessories		USB cable, cutting pad, safe blade, dedicated stand, tweezers, user’s manual, etc.

Depending upon the type, material that is 500 mm (19.6 in.) or longer may shift during cutting.
You may also be unable to cut some types of material.
According to material and cutting conditions as specified by Roland DG Corporation.
Excluding expansion/contraction of the material.
Range for assured repetition accuracy:
- For media with a width exceeding 610 mm (24 in.): Length: 4,000 mm (157 in.)
- For media with a width of 610 mm (24 in.) or less: Length: 8,000 mm (314 in.)

Software

Operating System		Application Software
Roland DG VersaWorks6 Ver. 6.10.0?	Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit)	—
Roland DG CutStudio	Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit)	—
Roland DG AAS?Plug-in for Adobe Illustrator (Windows)	Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit)	Adobe Illustrator CC (2014) / CC (2015) / CC (2017) / CC (2018) / CC (2019)/ CC (2020) / CC (2021)
Roland DG AAS? Plug-in for CorelDRAW (Windows)	Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit)	CorelDRAW Graphics Suite X7, X8, 2017, 2018, 2019, 2020

To contact Prytec Solutions about Roland DG Large Format Printer Machine 110 W | GR2 Vinyl Cutters use Get a quote.

Specifications:

Model		GR2-640	GR2-540
Drive system Cutting mechanism		Digital control servo motor Media-moving method
Acceptable material size (1)(2)
	Width:	Max. 70.1 in. (1,782 mm) Min. 1.97 in. (50 mm)	Max. 62.7 in. (1,594 mm) Min. 1.97 in. (50 mm)
	Thickness:	Thickness including backing paper is 0.8 mm (31.4 mil.) or less
	Roll weight:	52.9 lb. (24 kg)	44.1 lb. (20 kg)
Maximum cutting area		Width: 64 in. (1,627 mm) Length: 1,968 in. (50 m)	Width: 54 in. (1,372 mm) Length: 1,968 in. (50 m)
Usable Tools		CAMM-1 series blade (including blades for flatbed use)
Maximum cutting speed		1.19 to 60 in./s (30 to 1,530 mm/s)
Cutting force		5 – 600 gf
Mechanical resolution		0.236 mil./step (0.006 mm/step)
Software resolution		0.98 mil./step (0.025 mm/step)
Distance accuracy (*3)		Error of less than ±0.1% of distance traveled or 0.254 mm (10 mil.), whichever is greater
Repeatability (3)(4)(*5)		3.94 mil. (0.1 mm) or less
Connectivity		Ethernet (automatic switching between 10BASE-T and 100BASE-TX) USB 2.0 (FULL SPEED compliant) RS-232C
Replot memory		32 MB
Command system		HP-GL, HP-GL/2 compliant
Power requirements		AC 100 to 240 V ± 10%, 50/60 Hz
Power consumption		Approx. 110 W
Acoustic noise level		During operation 56 dB (A) or less During standby 40 dB (A) or less
Dimensions (Width x Depth x Height)		78.1 in. (W) x 30 in. (D) x 44.4 in. (H) 1,982 mm (W) x 756 mm (D) x 1,127 mm (H)	68 in. (W) x 25.7 in. (D) x 44 in. (H) 1,711 mm (W) x 651 mm (D) x 1,111 mm (H)
Weight		214 lb. (97 kg)	133 lb. (60 kg)
Packaging dimensions		87 in. (W) x 15.6 in. (D) x 34.7 in. (H) 2,200 mm (W) x 395 mm (D) x 880 mm (H)	81 in. (W) x 15.6 in. (D) x 33.5 in. (H) 2,040 mm (W) x 395 mm (D) x 850 mm (H)
Packaging weight		214 lb. (97 kg)	188 lb. (85 kg)
Operating environment		Temperature: 15 to 30 °c (59 to 86 °F), Humidity: 25 to 75% RH (no condensation)
Accessories		USB cable, cutting pad, safe blade, dedicated stand, tweezers, user’s manual, etc.

Depending upon the type, material that is 500 mm (19.6 in.) or longer may shift during cutting.
You may also be unable to cut some types of material.
According to material and cutting conditions as specified by Roland DG Corporation.
Excluding expansion/contraction of the material.
Range for assured repetition accuracy:
- For media with a width exceeding 610 mm (24 in.): Length: 4,000 mm (157 in.)
- For media with a width of 610 mm (24 in.) or less: Length: 8,000 mm (314 in.)

Software

Operating System		Application Software
Roland DG VersaWorks6 Ver. 6.10.0?	Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit)	—
Roland DG CutStudio	Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit)	—
Roland DG AAS?Plug-in for Adobe Illustrator (Windows)	Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit)	Adobe Illustrator CC (2014) / CC (2015) / CC (2017) / CC (2018) / CC (2019)/ CC (2020) / CC (2021)
Roland DG AAS? Plug-in for CorelDRAW (Windows)	Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit)	CorelDRAW Graphics Suite X7, X8, 2017, 2018, 2019, 2020

Read less...

To contact Prytec Solutions about Roland DG Large Format Printer Machine 110 W | GR2 Vinyl Cutters use Get a quote.
