Plate Freezer - VPF 36-810-600-102-1D Get latest price

Read more...

To contact Proquip Solutions Limited about Plate Freezer - VPF 36-810-600-102-1D use Get a quote.

Specifications of this product

• Product Type: Vertical Plate Freezer for offal blocks

• Station Size: 810 × 600 × 102 mm – 43.3 kg

• Block Size & Weight: 397 × 600 × 102 mm – 21.6 kg

• Number of Stations: 36 (2 blocks per station with 1 divider)

• Nominal Freezing Area: 810 × 600 mm (19 mm plate thickness)

• Capacity (All Units): 1,404 kg/hr nominal

• Refrigerant: R717 (Ammonia)

• Cycle Time: Approx. 200 minutes (including loading)

• Overall Dimensions (Per Unit): 5,297 × 1,324 × 1,269 mm – 3,000 kg

Features of this product

• Heavy-duty hot dip galvanised steel frame for long-term durability

• Food-safe aluminium plates (19 mm thick, seawater-resistant grade 6063) for optimal heat transfer

• Advanced hydraulic system with stainless steel cylinders and flow divider for smooth, even lifting

• Dual O-ring + gasket sealing system to minimise leaks and prevent corrosion

• Sliding plate and frame movement on HDPE/Acetal for low wear and smooth operation

• Designed for hygiene with stainless steel covers and easy-clean access points

Applications of this product

• Freezing offal and meat-based products in block form

• Ideal for large-scale meat processing facilities

• Suitable for operations requiring high-throughput, batch freezing with consistent results

Why choose this product

• Proven industrial design delivering 1,404 kg/hr nominal capacity across three units

• Robust construction built for long service life in demanding environments

• Reliable R717 ammonia refrigeration for efficient, uniform freezing

• Second-hand purchase offers substantial cost savings over new without sacrificing performance
