The HIKMICRO SP60 is a state-of-the-art handheld infrared thermal imaging camera designed for high-precision temperature measurement, industrial inspection, and predictive diagnostics. Built for professionals across electrical, mechanical, HVAC, energy, and utility industries, the SP60 combines exceptional resolution, advanced imaging modes, and robust data reporting to deliver uncompromising performance and efficiency.

Key Features

• Thermal resolution: 640 × 480 (307,200 pixels), enhanced to 1280 × 960 with Super IR
• Thermal sensitivity (NETD): < 30 mK @ 30°C
• Temperature range: -20°C to 650°C (extendable up to 2200°C optional)
• Accuracy: ±2°C or ±2% of reading
• Laser-assisted auto focus and manual focus system with built-in distance meter
• 5.0” high-resolution LCD capacitive touchscreen
• Built-in viewfinder with rotating lens block for ergonomic use in any environment
• Advanced imaging modes: Thermal, Visual, Fusion, Blending, Picture-in-Picture
• Removable 128 GB SD card for image storage
• Connectivity: Wi-Fi, USB-C, HDMI with HIKMICRO Viewer software support
• Battery life: Approx. 4 hours per battery (includes 2 batteries for extended operation)
• Rugged IP54-rated housing, 1 m drop-tested, <1.5 kg weight including battery

Applications

• Electrical inspections: Detect faulty breakers, overloaded circuits, failing connections
• Mechanical maintenance: Identify hotspots in bearings, motors, pumps, conveyors
• HVAC and building diagnostics: Locate insulation failures, leaks, moisture intrusion
• Solar and renewable energy: Inspect solar arrays, battery banks, electrical faults
• Oil, gas, and utilities: Monitor pipelines, transformers, substations, high-voltage systems

Benefits

• Unparalleled clarity with high-resolution 640 × 480 detector and <30 mK sensitivity
• Professional-grade durability and ergonomic design with rotating lens and viewfinder
• Smart connectivity with Wi-Fi, USB-C, HDMI, and instant reporting capabilities
• Upgradeable performance with optional high-temperature range up to 2200°C
• Lightweight yet rugged build for demanding field conditions

Technical Specifications

IR Resolution: 640 × 480 (Super IR: 1280 × 960)

NETD: < 30 mK @ 30°C

Temperature Range: -20°C to 650°C (2200°C optional)

Accuracy: ±2°C or ±2%

Focus: Laser-assisted auto + manual

Display: 5.0” LCD touchscreen + built-in viewfinder

Image Modes: Thermal, Visual, Fusion, Blending, PIP

Storage: Removable 128 GB SD card

Connectivity: Wi-Fi, USB-C, HDMI

Protection Rating: IP54

Drop Resistance: 1 m

Battery Life: 4 hours per battery (2 included)

Weight: < 1.5 kg (with battery)

Package Includes

• HIKMICRO SP60 Thermal Imaging Camera
• 2 × rechargeable Li-ion batteries and charging dock
• USB-C cable
• Hard carrying case
• Neck strap and wrist strap
• Calibration certificate
• Quick start guide
• HIKMICRO Viewer software access

Why Choose the HIKMICRO SP60?

With industry-leading resolution, <30 mK sensitivity, and smart connectivity, the HIKMICRO SP60 delivers unmatched thermal clarity and operational insight. It is engineered for professionals who demand precision, durability, and efficiency in the field.
