GSR - GSR E190THD 19m Truck Mounted EWP Get latest price

Read more...

To contact Monitor about GSR GSR E190THD 19m Truck Mounted EWP use Get a quote.

It is built to accommodate 2 persons and tools with a maximum rated capacity of 220 kg. Even though the Monitor E190THD only weighs 8.5 t, it can still manage 18.52 m of working height, 16.52 m of platform height, and 13.20 m of horizontal reach.

It features internal protected hoses with self-cleaning brushes on the telescopic sections to prevent ingress of dirt and other debris, and is particularly suited to heavy duty applications with its all-steel and strong profile design.

Specifications:

Max. Working Height:

18.52 m

Max. Working Reach:

16.52 m

Max. Platform Height:

14.00 m

Capacity:

250 kg

Turret Rotation:

450°

Min. Transport Length:

7.76 m

Min. Transport Width:

2.40 m

Min. Transport Height:

3.27 m

Power:

PTO from Vehicle
