Adjustable Length Cable Seals Ca. 50 kg | Unisto Modulo 1 Get latest price

Read more...

To contact Safepak about Adjustable Length Cable Seals Ca. 50 kg | Unisto Modulo 1 use Get a quote.

Mainly used in the Retail, Logstic and Transport sectors. Unisto Modulo 1 offers lengths of ribbon from 400 mm to 2800 mm. The concept of the seal enables to insert the ribbon in a hole of minimum 5 x 2 mm. Bar-coding ensures fast and accurate data capture and streamlines any process. Various colours for logistical function available.

Features of this security seal

Type of Seal

Adjustable Length Seals

Application

Boxes and Cases, Diverse

• Long lengths : the length of the ribbon from 400 mm to 2800 mm with pitch of 10 mm enables many applications which are currently not possible with other seals
• Two colour seal
• High resistance through small width of the ribbon
• The design of the seal enables to insert the ribbon in a hole of minimum 5x2 mm
• Locking mechanism of POM increases security level
• Various colours for logistical functions (colour coding)
• On request tightening tool for a possible use as strap for distribution boxes
• Customer name/logo for clear identification
• Bar-coding ensures fast and accurate data capture
• Large tag to cater more information if necessary
• Mats of 2 to 10 seals allow easy and controlled distribution of seals in sequence
• Patented
• Recyclable

Specifications:

Materials

Polypropylene Locking mechanism: POM

Length

All lengths possible between a minimum of 400 mm and 2800 mm with pitch of 10 mm

Tensile strength (loop)

Ca. 50 kg

Barcode & numbering

Directly laser marked

Code 2/5 interleaved, 39, 128 A-B-C

On request: code 2D, RFID

Customer name/logo

Foil printed in 1 colour or directly laser marked

Colours

Tag and ribbon end: white, blue, yellow, green, pink, brown (pastel colours). Ribbon: red

Packing

Mats of 2 to 10 seals, bunches of 50 and boxes of

500 pieces (for ribbon length ≤ 1000 mm)

Mats of 2 to 10 seals, bunches of 10 and boxes of

250 pieces (for ribbon length > 1000 mm)

250 : 56.0 x 35.5 x 25.0 cm (0.050 m3), approx. 4.8 kg

500 : 56.0 x 35.5 x 25.0 cm (0.050 m3), approx. 6.8 kg

Storage

Seals should be stored in original box away from direct sunlight and chemical fumes.

Store at 22°C/50% RH. Typical shelf life of seals made of PP and PA are approx. 18 months from date of manufacture.

Nevertheless please do not order more than an annual quantity.
