XCMG Articulated Dump Truck | XDA45U

XCMG - Articulated Dump Truck | XDA45U

Supplier: XCMG Sales and Service

Articulated Dump Truck | XDA45U

The world-renowned 41-tonne payload XDA45U Articulated Dump Truck is designed for use in mining, quarry, water conservation, harbour, brown field and construction sites.

Receive 1-3 days from order

With a powerful drivetrain, superior hauling performance, and excellent manoeuvrability and efficiency, the XDA45U delivers exceptional results across a wide range of applications.

The XDA45U is also designed to run continuously in operating environments ranging from -25 degrees Celsius to 40 degrees Celsius, and meets Euro V emission standards.

Features of this product

Technically advanced powerful Benz engine that is specially designed for mining operation lowers fuel consumption and increases working efficiency.
The pump controlling hydraulic system and load-sensitive steering system enhance system stability, quicken trouble shooting and save more energy.
The application of XCMG’s exclusive travel control strategy and fault analysis system makes the overall vehicle more intelligent.
6×6 drive and friction-disk type inter-wheel/inter-axle differential locks take passing performance, reliability and riding stability to a higher level.
ROPS & FOPS that meet ISO standards are equipped in driver’s cab, which enlarges interior space, broadens field of view range, secures driver’s working safety and increases comfort.
Driver’s cab and engine hood are both flipping designs, and the cab is integrated with a centralised lubrication system, all these designs make maintenance more convenient and more efficient.

Specifications of this product

Overall Length:11,070 mm
Overall Width: 3,950 mm
Overall Height: 3,846 mm
Total Weight: 75,000 kg
Payload: 41,000 kg
Curb Weight: 34,000 kg
Engine: Benz OM471 (Germany)
Rated Power: 390 kw / 1600 rpm
Max Torque: 2600 Nm / 1300 rpm
Drive: 6 x 6
Max Speed: 51 km/h
Min Turning Clearance: 9275 mm

To contact XCMG Sales and Service about XCMG Articulated Dump Truck | XDA45U use Get a quote.
