FEATURES

1. DUST SUPPRESSION SYSTEM (OPTION): Water spray system fitted to the forward product conveyor
2. POWERPACK CATERPILLAR®: engine as standard, compliant to industry regulations
3. CONE CRUSHER: Striker CS cones offer excellent capacities for their size. Hydraulic adjustment and clearing as standard with automatic overload protection
4. ACCESS & WAKLWAYS: Access platforms to hydraulic tank, engine, cone crusher and feed hopper
5. FEED HOPPER: Manufactured from Hardox® steel with impact diverter bars to protect the heavy duty feeder belt
6. BELT CONVEYOR: Variable belt speed for a controlled continuous feed, monitored by a flow sensor
7. FORWARD PRODUCT CONVEYOR: Extra wide product conveyor with full length rubber side skirts utilising Hardox® clamp plates. Maximised discharge height for product stockpiling. Optional screen and recirculating conveyor can be provided
8. EXTRA HEAVY DUTY: Welded robust steel chassis
9. TRACK FRAME: Heavy duty tracks suitable for any environment
10. LUBRICATION COOLER: Efficient lubrication cooler to ensure reliable operation
11. LIFTING BRACKET: Lifting bracket fitted to allow easy loading for break bulk shipping
12. E-TRAC: E-trac option available

SPECIFICATION

• Feeder Capacity: 5m³/7m³
• Crusher Size: 0.9m
• Feed Opening: 1.2m
• Power Pack: C9.3 310kW
• Weight: 41T
• Operation Dimension: L 14.6m x W 2.8m x H 4.2m
• Transport Dimension: L 15.4m x W 2.8m x H 3.6m
