LCR Meter IM3533

From R&D Applications to Windings, Coil and Transformer Manufacturing

Receive 1-3 days from order

Hioki LCR Meters and Impedance Analyzers range from 1 mHz to 3 GHz devices to suit a wide range of applications in the testing of electronic components. The IM3533 series are Hioki’s first LCR meters to offer turn ratio, mutual inductance and inductance difference measurements of transformers and coils, and are integrated with an internal DC bias to facilitate HDMI compliance testing.

Key Features

±0.05% accuracy with wide measurement range
(DC, 1mHz to 200kHz, 5mV to 5V, 10uA to 50mA)
Non-stop testing over mixed measurement conditions such as C-D and ESR at 10 times the speed of previous models
Built-in low impedance high precision mode effective for testing low inductance or the ESR of aluminum electrolysis capacitance
Dedicated modes for measuring transformer winding ratio, mutual inductance and temperature compensated DCR
Frequency sweep testing (IM3533-01 only)
2m/4m cable setting in addition to the standard 0m/1m
Touch screen with intuitive operation

Model No. (Order Code)

IM3533
IM3533-01 Advanced function model

This product is not supplied with measurement probes or test fixtures. Please select and purchase the measurement probe or test fixture options appropriate for your application separately. All probes are constructed with a 1.5D-2V coaxial cable. For an RS-232C connection: A crossover cable for interconnection can be used. You can use the RS-232C CABLE 9637 without hardware flow control.

To contact NWI Group about Hioki LCR Meter IM3533 use Get a quote.

Key Features

±0.05% accuracy with wide measurement range
(DC, 1mHz to 200kHz, 5mV to 5V, 10uA to 50mA)
Non-stop testing over mixed measurement conditions such as C-D and ESR at 10 times the speed of previous models
Built-in low impedance high precision mode effective for testing low inductance or the ESR of aluminum electrolysis capacitance
Dedicated modes for measuring transformer winding ratio, mutual inductance and temperature compensated DCR
Frequency sweep testing (IM3533-01 only)
2m/4m cable setting in addition to the standard 0m/1m
Touch screen with intuitive operation

Model No. (Order Code)

IM3533
IM3533-01 Advanced function model

Read less...

To contact NWI Group about Hioki LCR Meter IM3533 use Get a quote.
