ATV 695cc liquid-cooled EFI engine | Xplorer XR 700

At times you need to calm the chaos in your head from your non-stop life. To do so, you need to self-reflect, think deep and take care of the person who matters most — that’s you. At ARGO, we believe riding helps you recharge and relax.

Receive 1-3 days from order

The 2024 XR 700 EPS has a powerful way to help you forget about your distracting to-do list and constant naysayers. Its smooth ride provided by front and rear double A-arm suspension, 695cc liquid-cooled EFI engine, electric power steering (EPS) and exceptional ergonomics, allows you to focus on the dirt trail in front of you. The XR 700 EPS will do wonders on the trail and with your soul. That’s on purpose.

Specifications:

DISPLACEMENT	695CC
ENGINE STROKE	4-STROKE
CYLINDER ARRANGEMENT	SOHC SINGLE-CYLINDER
VALVE CONFIGURATION	4 VALVE
FUEL SYSTEM	EFI
COOLING SYSTEM	LIQUID
BORE X STROKE	102 X 85.2 MM
COMPRESSION RATIO	10.7:1
START METHOD	ELECTRIC START
IGNITION	ECU
OVER RIDE BUTTON	N/A
TRANSMISSION TYPE	CVT AUTOMATIC
FINAL DRIVE	SHAFT DRIVE
DIFFERENTIAL FUNCTION	FRONT DIFFERENTIAL
DRIVE SYSTEM TYPE	ELECTRONIC 2WD/ 4WD /LOCK
ELECTRIC DIFF LOCK	YES
GEAR SELECTION	H/L/N/R/P
REVERSE	YES
ENGINE BRAKING SYSTEM (EBS)	STANDARD
LENGTH	84.3 IN (2,140 MM)
WIDTH	49 IN (1,245 MM)
HEIGHT	49.2 IN (1,250 MM)
SEAT HEIGHT	34.6 IN (880 MM)
GROUND CLEARANCE	10.2 IN (260 MM)
WHEELBASE	51.1 IN (1,297 MM)
TOWING CAPACITY	1,000 LBS (454 KG)
DRY WEIGHT	705 LBS (320 KG)
WET WEIGHT	736 LBS (334 KG)
FUEL TANK CAPACITY	5.5 GAL (21L)
RIDER CAPACITY	1
SUSPENSION - FRONT	INDEPENDENT DOUBLE A-ARM
SUSPENSION - REAR	INDEPENDENT DOUBLE A-ARM W SWAY BAR
SUSPENSION TRAVEL - FRONT	7 IN (176 MM)
SUSPENSION TRAVEL - REAR	7.4 IN (188 MM)
BRAKE - FRONT	DUAL HYDRAULIC ??DISC
BRAKE - REAR	HYDRAULIC ?DISC
FOOT BRAKE	STANDARD
TIRE SIZE (FRONT)	AT25X8-12
TIRE SIZE (REAR)	AT25X10-12
WHEEL RIM	STEEL
ELECTRIC POWER STEERING	YES
BATTERY	12V 18ah AGM
FRONT RACK	114 LB (52 KG)
REAR RACK	209 LB (95 KG)
FRONT BUMPER	N/A
HITCH	STANDARD/2" RECEIVER
WINCH	3,000 LB WINCH
HAND GUARD	N/A
12V CHARGER	N/A
DAYLIGHT STRIP	STANDARD
SKID PLATE	PLASTIC
PASSENGER HANDLES	NO
PASSENGER BACKREST	NO
STORAGE	CENTER CONSOLE AND LOCKABLE FRONT FENDER
FRONT BRUSH GUARD	ACCESSORY
REAR BUMPER	ACCESSORY
FRONT RACK EXTENTION	ACCESSORY
REAR RACK EXTENTION	ACCESSORY
USB CHARGING PORT	STANDARD
REAR BOX STORAGE	N/A
INSTRUMENTATION	DIGITAL INSTRUMENT PANEL WITH ODOMETER, SPEEDMETER, TRIPMETER, RPM, TRANSMISSION POSITION, 2WD/4WD/LOCK INDICATOR, FUEL GAUGE, TEMPERATURE, LOW-BATTERY, HIGH BEAM LIGHT AND CHECK ENGINE LIGHTS
LIGHTING	DUAL 12V 35W HIGH/LOW BEAM, DUAL WITH BRAKE LIGHT
WARRANTY	1 YEAR
COLOR	RED OR GREEN
