Reach Stackers 45T | RS45–46

The Hyster Reach Stackers are available in both container handling (CH) and intermodal handling (IH) versions for high density container stacking applications up to 5-high and 3-rows deep.

Video for Hyster Reach Stackers 45T | RS45–46

Receive 1-3 days from order

This machine has been designed to achieve maximum space utilisation on container terminals, thanks to outstanding manoeuvrability, superior handling speeds and unrestricted stacking capabilities, in an all-in-one package.

The series is available with a modern clean-running Diesel engine, standard oil-immersed brakes, robust drive-axle and advanced auto-shift transmission, which all combine to maintain maximum productivity and reliability during operation in demanding applications.

Engine and transmission protection systems as well as oil-immersed brakes are standard to ensure reliable operation.
The Hyster “Vista” cab, offers an outstanding range of standard ergonomic features, plus a sliding mechanism as standard for optimum container visibility in varying operating conditions.
The hydraulic system is highly efficient, and features ‘Power on Demand’ and ‘Two-Speed Lift’ functions, delivering class leading lifting speeds.
Increased capacity handling available thanks to models available with stabilisers and/or increased wheelbase.
Immensely strong frame and boom construction to handle the high capacity handling operation.
An engine shutdown function and easy service access minimise cost and service time.

Specifications

Model	Load Capacity (kg)	Load Centre (mm)	Lift Height (mm)	Engine	Transmission	Stacking Height 1st Row	Stacking Height 2nd Row	Stacking Height 3rd Row	Load Capacity (kg) 1st Row	Load Capacity (kg) 2nd Row	Load Capacity (kg) 3rd Row
RS45-27 CH	45000	1565	15150	Cummins / QSL9 227KW	S.O.H. / TE-27 4-Speed Transmission	5 / 5	5 / 4	3 / 3	45000	27000	12300
RS45-31 CH	45000	1565	15150	Cummins / QSL9 227KW	S.O.H. / TE-27 4-Speed Transmission	5 / 5	5 / 4	3 / 3	45000	31000	15000

To contact Adaptalift Group about Hyster Reach Stackers 45T | RS45–46 use Get a quote.

Engine and transmission protection systems as well as oil-immersed brakes are standard to ensure reliable operation.
The Hyster “Vista” cab, offers an outstanding range of standard ergonomic features, plus a sliding mechanism as standard for optimum container visibility in varying operating conditions.
The hydraulic system is highly efficient, and features ‘Power on Demand’ and ‘Two-Speed Lift’ functions, delivering class leading lifting speeds.
Increased capacity handling available thanks to models available with stabilisers and/or increased wheelbase.
Immensely strong frame and boom construction to handle the high capacity handling operation.
An engine shutdown function and easy service access minimise cost and service time.

Specifications

Model	Load Capacity (kg)	Load Centre (mm)	Lift Height (mm)	Engine	Transmission	Stacking Height 1st Row	Stacking Height 2nd Row	Stacking Height 3rd Row	Load Capacity (kg) 1st Row	Load Capacity (kg) 2nd Row	Load Capacity (kg) 3rd Row
RS45-27 CH	45000	1565	15150	Cummins / QSL9 227KW	S.O.H. / TE-27 4-Speed Transmission	5 / 5	5 / 4	3 / 3	45000	27000	12300
RS45-31 CH	45000	1565	15150	Cummins / QSL9 227KW	S.O.H. / TE-27 4-Speed Transmission	5 / 5	5 / 4	3 / 3	45000	31000	15000

Read less...

To contact Adaptalift Group about Hyster Reach Stackers 45T | RS45–46 use Get a quote.
