Agricultural Mower & Mulcher 4.0-4.95m | Discbine Center-pivot

Supplier: New Holland Agriculture

New Holland has taken the Discbine® mower-conditioner to a new level with two new center-pivot models. Combining both speed and performance, the new models enhance the entire Discbine® line with a new 4.0 metre and 4.95 metre Disc Mower Conditioner.

Receive 1-3 days from order

The new Discbine® 313 and Discbine® 316 are designed with increased durability and features that lead to cleaner cutting, more efficient crop flow and smoother, more effective conditioning.

Available Models:

Discbine® 313 (roll)
Discbine® 313 (flail)
Discbine® 316 (roll)
Discbine® 316 (flail)

Specifications:

Discbine® 313 (roll)	Discbine® 313 (flail)	Discbine® 316 (roll)	Discbine® 316 (flail)
MowMax II Cutterbar with ShockPRO hubs
Cutting width (m)	4.00	4.00	4.95	4.95
Cutting height (mm)	19-70	19-70	19-70	19-70
Cutting height w/opt. high-stubble shoes (mm)	76-140	76-140	76-140	76-140
Cutting height w/opt. Biomass shoes (mm)	127-198	127-198	127-198	127-198
Cutting height w/opt. adjustable shoes (mm)	19-146	19-146	19-146	19-146
Cutterbar tilt angle degrees	2-10	2-10	2-10	2-10
Type cutterbar	Modular	Modular	Modular	Modular
Number of discs/knives per disc	8/2	8/2	10/2	10/2
Disc speed @ 1000 rpm PTO speed (rpm)	2250	2250	2250	2250
Knife tip speed @ 1000 rpm PTO speed (kph)	261	261	261	261
Cutterbar flotation	Vertical and lateral, adjustable springs	Vertical and lateral, adjustable springs	Vertical and lateral, adjustable springs	Vertical and lateral, adjustable springs
Cutterbar drive method	PTO drive w/slip clutch to bevel gearbox at LH end of header, vertical PTO shaft to cutterbar, replaceable ShockPRO disc drive hubs	PTO drive w/slip clutch to bevel gearbox at LH end of header, vertical PTO shaft to cutterbar, replaceable ShockPRO disc drive hubs	PTO drive w/slip clutch to bevel gearbox at LH end of header, vertical PTO shaft to cutterbar, replaceable ShockPRO disc drive hubs	PTO drive w/slip clutch to bevel gearbox at LH end of header, vertical PTO shaft to cutterbar, replaceable ShockPRO disc drive hubs

To contact New Holland Agriculture about Agricultural Mower & Mulcher 4.0-4.95m | Discbine Center-pivot use Get a quote.

The new Discbine® 313 and Discbine® 316 are designed with increased durability and features that lead to cleaner cutting, more efficient crop flow and smoother, more effective conditioning.

Available Models:

Discbine® 313 (roll)
Discbine® 313 (flail)
Discbine® 316 (roll)
Discbine® 316 (flail)

Specifications:

Discbine® 313 (roll)	Discbine® 313 (flail)	Discbine® 316 (roll)	Discbine® 316 (flail)
MowMax II Cutterbar with ShockPRO hubs
Cutting width (m)	4.00	4.00	4.95	4.95
Cutting height (mm)	19-70	19-70	19-70	19-70
Cutting height w/opt. high-stubble shoes (mm)	76-140	76-140	76-140	76-140
Cutting height w/opt. Biomass shoes (mm)	127-198	127-198	127-198	127-198
Cutting height w/opt. adjustable shoes (mm)	19-146	19-146	19-146	19-146
Cutterbar tilt angle degrees	2-10	2-10	2-10	2-10
Type cutterbar	Modular	Modular	Modular	Modular
Number of discs/knives per disc	8/2	8/2	10/2	10/2
Disc speed @ 1000 rpm PTO speed (rpm)	2250	2250	2250	2250
Knife tip speed @ 1000 rpm PTO speed (kph)	261	261	261	261
Cutterbar flotation	Vertical and lateral, adjustable springs	Vertical and lateral, adjustable springs	Vertical and lateral, adjustable springs	Vertical and lateral, adjustable springs
Cutterbar drive method	PTO drive w/slip clutch to bevel gearbox at LH end of header, vertical PTO shaft to cutterbar, replaceable ShockPRO disc drive hubs	PTO drive w/slip clutch to bevel gearbox at LH end of header, vertical PTO shaft to cutterbar, replaceable ShockPRO disc drive hubs	PTO drive w/slip clutch to bevel gearbox at LH end of header, vertical PTO shaft to cutterbar, replaceable ShockPRO disc drive hubs	PTO drive w/slip clutch to bevel gearbox at LH end of header, vertical PTO shaft to cutterbar, replaceable ShockPRO disc drive hubs

Read less...

To contact New Holland Agriculture about Agricultural Mower & Mulcher 4.0-4.95m | Discbine Center-pivot use Get a quote.

discbine-center-pivot-disc-mower-conditioners-brochure-apac-anz(1.61MB)
